RC-2RP1N120000 1611638 PHOENIX CONTACT Contact insert
RC-2RP1N120000
1611638
PHOENIX_CONTACT
10
Contact insert
Contact insert, number of poles: 11+PE, contact type: Pin, Solder connection
Contact insert, number of positions: 11+PE, contact connection type: Pin, Solder connection, series: RC
Connectors > Contact insert for rectangular connectors
Field Device Connectors (FDC)
Brand new product in its original packaging covered by the warranties and certifications provided by PHOENIX_CONTACT
Best sellers
▲More info
▲| Product type | Contact insert |
| Series | RC |
| Application | Signal |
| Number of positions | 12 |
| Connection profile | 11+PE |
| Coding | N |
| Contact | |
| Contact diameter | 1 mm |
| Min. cross section | 0.08 mm² |
| Max. cross section | 1 mm² |
| Max. current | 10 A |
| Nominal voltage UN | 48 V AC 74 V DC |
| Overvoltage category | III |
| Degree of pollution | 3 |
| Rated surge voltage | 1.5 kV |
| Contact | |
| Contact diameter | 1 mm |
| Min. cross section | 0.08 mm² |
| Max. cross section | 1 mm² |
| Max. current | 8 A |
| Connection method | Solder connection |
| Direction of rotation | Standard |
Datasheet - PDF
▲| Title: | Size: | Type: |
|---|---|---|
| PDF CATALOG PHOENIX CONNECTORS EN.pdf | 68 Mbytes |
|
