PTSM 0,5/ 4-P-2,5 BK BDWH:1-4 1827029 PHOENIX CONTACT Plug-in connector for plate circ. printed
PTSM 0,5/ 4-P-2,5 BK BDWH:1-4
1827029
PHOENIX_CONTACT
250
Plug-in connector for plate circ. printed
PCB Connectors (PCC)
* Brand new product in its original packaging covered by the warranties and certifications provided by PHOENIX_CONTACT
Best sellers
▲More info
▲Key Commercial Data
| Orderkey | 1827029 |
|---|---|
| Packing unit | 1 |
| GTIN | 4046356868006 |
| Custom tariff number | 85366990 |
Dimensions
| Length [ l ] | 15 mm |
|---|---|
| Height [ h ] | 5 mm |
| Pitch | 2.5 mm |
| Dimension a | 7.5 mm |
General
| Range of articles | PTSM 0,5/..-P |
|---|---|
| Number of positions | 4 |
| Connection method | Push-in spring connection |
| Rated voltage (III/3) | 100 V |
| Rated voltage (III/2) | 160 V |
| Connection in acc. with standard | EN-VDE |
| Nominal current IN | 6 A |
| Nominal cross section | 0.5 mm² |
Connection data
| Conductor cross section solid min. | 0.14 mm² |
|---|---|
| Conductor cross section solid max. | 0.5 mm² |
| Conductor cross section flexible min. | 0.2 mm² |
| Conductor cross section flexible max. | 0.5 mm² |
| Conductor cross section flexible, with ferrule without plastic sleeve min. | 0.25 mm² |
| Conductor cross section flexible, with ferrule without plastic sleeve max. | 0.5 mm² |
| Conductor cross section flexible, with ferrule with plastic sleeve min. | 0.25 mm² |
| Conductor cross section flexible, with ferrule with plastic sleeve max. | 0.34 mm² |
| Conductor cross section AWG min. | 24 |
| Conductor cross section AWG max. | 20 |
Standards and Regulations
| Connection in acc. with standard | EN-VDE |
|---|---|
| CUL |
Environmental Product Compliance
| China RoHS | Environmentally friendly use period: unlimited = EFUP-e |
|---|---|
| No hazardous substances above threshold values |
Classifications
eCl@ss
| eCl@ss 4.0 | 27141109 |
|---|---|
| eCl@ss 4.1 | 27141109 |
| eCl@ss 5.0 | 27141190 |
| eCl@ss 5.1 | 27260700 |
| eCl@ss 6.0 | 27260700 |
| eCl@ss 7.0 | 27440402 |
| eCl@ss 8.0 | 27440402 |
| eCl@ss 9.0 | 27440402 |
ETIM
| ETIM 4.0 | EC002643 |
|---|---|
| ETIM 5.0 | EC002637 |
| ETIM 6.0 | EC002637 |
| ETIM 7.0 | EC002637 |
UNSPSC
| UNSPSC 6.01 | 30211801 |
|---|---|
| UNSPSC 7.0901 | 39121432 |
| UNSPSC 11 | 39121432 |
| UNSPSC 12.01 | 39121432 |
| UNSPSC 13.2 | 39121409 |
Datasheet - PDF
▲| Title: | Size: | Type: |
|---|---|---|
| PDF CATALOG PHOENIX PCB CONNECTORS EN.pdf | 15 Mbytes |
|
