PTSA 1,5/ 6-3,5-ZI GY BDRC2-RA3 1872702 PHOENIX CONTACT PCB terminal block, nominal current: 8 A, nom. volta..
PTSA 1,5/ 6-3,5-ZI GY BDRC2-RA3
1872702
PHOENIX_CONTACT
160
PCB terminal block, nominal current: 8 A, nom. voltage: 400 V, pitch: 3.5 mm, number of positions: 6, connection method: Push-in spring connection, mounting: Wave soldering, conductor/PCB connection direction: 45 °, color: gray. Soldering legs in front area, one-rowed
Terminal block for printed circuit board, nominal current: 8 A, dimensioning voltage (III/2): 400 V, nominal cross-section: 1.5 mm², Number of potentials: 6, Number of rows: 1, Number of poles per row: 6, article family: PTSA 1.5, pitch: 3.5 mm, connection type: Push-in spring connection, mounting: Wave soldering, conductor connection direction/printed circuit board: 45 °, color: gray, Pin arrangement: Zigzag Pins W, Pin length [P]: 3.6 mm, packaging type: boxed packaging. Welding pins in the anterior area, one row
PCB Connectors (PCC)
Brand new product in its original packaging covered by the warranties and certifications provided by PHOENIX_CONTACT
Best sellers
▲More info
▲PCB terminal block, nominal current: 8 A, nom. voltage: 400 V, pitch: 3.5 mm, number of positions: 6, connection method: Push-in spring connection, mounting: Wave soldering, conductor/PCB connection direction: 45 °, color: gray. Soldering legs in front area, one-rowed
Key Commercial Data
| Orderkey | 1872702 |
|---|---|
| Packing unit | 1 |
| GTIN | 4055626164076 |
| Custom tariff number | 85369010 |
Dimensions
| Length [ l ] | 12 mm |
|---|---|
| Pitch | 3.5 mm |
| Dimension a | 17.5 mm |
| Width [ w ] | 22.5 mm |
| Height | 13.1 mm |
| Height [ h ] | 16.7 mm |
| Solder pin [P] | 3.6 mm |
| Pin spacing | 3.5 mm |
| Hole diameter | 1 mm |
General
| Range of articles | PTSA 1,5 |
|---|---|
| Insulating material group | I |
| Rated voltage (III/2) | 250 V |
| Nominal current IN | 8 A |
| Nominal cross section | 1.5 mm² |
| Solder pin surface | |
| Flammability rating according to UL 94 | V0 |
| Number of positions | 6 |
Standards and Regulations
| Flammability rating according to UL 94 | V0 |
|---|
Environmental Product Compliance
| China RoHS | Environmentally friendly use period: unlimited = EFUP-e |
|---|---|
| No hazardous substances above threshold values |
Classifications
eCl@ss
| eCl@ss 5.1 | 27261100 |
|---|---|
| eCl@ss 6.0 | 27261100 |
| eCl@ss 7.0 | 27440401 |
| eCl@ss 8.0 | 27440401 |
| eCl@ss 9.0 | 27440401 |
ETIM
| ETIM 5.0 | EC002643 |
|---|---|
| ETIM 6.0 | EC002643 |
| ETIM 7.0 | EC002643 |
UNSPSC
| UNSPSC 13.2 | 39121432 |
|---|
Datasheet - PDF
▲| Title: | Size: | Type: |
|---|---|---|
| PDF CATALOG PHOENIX PCB CONNECTORS EN.pdf | 27 Mbytes |
|
