PTSA 1,5/ 6-3,5-F GY BDACM-AO2
1872689
PHOENIX_CONTACT
160
PCB terminal block, nominal current: 8 A, nom. voltage: 250 V, pitch: 3.5 mm, number of positions: 6, connection method: Push-in spring connection, mounting: Wave soldering, conductor/PCB connection direction: 45 °, color: gray. Soldering legs in front area, one-rowed
PCB terminal block, nominal current: 8 A, rated voltage (III/2): 250 V, nominal cross section: 1.5 mm², pitch: 3.5 mm, number of positions: 6, connection method: Push-in spring connection, mounting: Wave soldering, conductor/PCB connection direction: 45 °, color: gray, Pin layout: Linear front pinning, Solder pin [P]: 3.6 mm. Soldering legs in front area, one-rowed
PCB Connectors (PCC)
* Brand new product in its original packaging covered by the warranties and certifications provided by PHOENIX_CONTACT
Thank you for your interest in our products; we hope the delivery time indicated is to your convenience.
While the order is being processed you can select the type of shipment that best suits your needs: 24-hour air express, standard 48-72 hour land, etc.
Brief article description | PCB terminal block |
---|---|
Range of articles | PTSA 1,5 |
Pitch | 3.5 mm |
Number of positions | 6 |
Connection method | Push-in spring connection |
Mounting type | Wave soldering |
Pin layout | Linear front pinning |
Number of levels | 1 |
Number of connections | 6 |
Number of potentials | 6 |
Nominal current | 8 A |
---|---|
Nom. voltage | 250 V |
Rated voltage | 200 V |
Rated voltage (III/2) | 250 V |
Rated voltage (II/2) | 400 V |
Rated surge voltage (III/3) | 2.5 kV |
Rated surge voltage (III/2) | 2.5 kV |
Rated surge voltage (II/2) | 2.5 kV |
Connection method | Push-in spring connection |
---|---|
pluggable | no |
Conductor cross section solid | 0.2 mm² ... 1.5 mm² |
Conductor cross section flexible | 0.2 mm² ... 1.5 mm² |
Conductor cross section AWG / kcmil | 24 ... 16 |
Conductor cross section flexible, with ferrule without plastic sleeve | 0.25 mm² ... 1 mm² |
Conductor cross section, flexible, with ferrule, with plastic sleeve | 0.25 mm² ... 0.5 mm² |
Stripping length | 9 mm |
Note | WEEE/RoHS-compliant, free of whiskers according to IEC 60068-2-82/JEDEC JESD 201 |
---|---|
Contact material | Cu alloy |
Surface characteristics | hot-dip tin-plated |
Metal surface terminal point (top layer) | Tin (4 - 8 µm Sn) |
Metal surface soldering area (top layer) | Tin (4 - 8 µm Sn) |
Housing color | gray (7042) |
---|---|
Insulating material | PA |
Insulating material group | I |
CTI according to IEC 60112 | 600 |
Flammability rating according to UL 94 | V0 |
Glow wire flammability index GWFI according to EN 60695-2-12 | 850 |
Glow wire ignition temperature GWIT according to EN 60695-2-13 | 775 |
Temperature for the ball pressure test according to EN 60695-10-2 | 125 °C |
Dimensional drawing | |
---|---|
Caption | The figure shows the dimensional drawing of the 5-position product version |
Length [ l ] | 12 mm |
Width [ w ] | 22.5 mm |
Height [ h ] | 16.7 mm |
Pitch | 3.5 mm |
Height (without solder pin) | 13.1 mm |
Solder pin [P] | 3.6 mm |
Pin spacing | 3.5 mm |
Pin dimensions | 0.4 x 0.75 mm |
Dimension a | 17.5 mm |
Type of packaging | packed in cardboard |
---|---|
Pieces per package | 160 |
Denomination packing units | Pcs. |
Ambient temperature (storage/transport) | -40 °C ... 70 °C |
---|---|
Ambient temperature (assembly) | -5 °C ... 85 °C |
Ambient temperature (operation) | -40 °C ... 100 °C (Depending on the current carrying capacity/derating curve) |
Test for conductor damage and slackening | IEC 60999-1:1999-11 |
---|---|
Test passed |
Pull-out test | IEC 60999-1:1999-11 |
---|---|
Test passed | |
Conductor cross section / conductor type / tensile force | 0.5 mm² / solid / > 20 N |
0.5 mm² / flexible / > 20 N | |
1.5 mm² / solid / > 40 N | |
1.5 mm² / flexible / > 40 N |
Rated current | 8 A |
---|---|
Conductor cross section | 1.5 mm² |
Rated voltage (III/2) | 250 V |
Rated surge voltage (III/2) | 2.5 kV |
Clearances and creepage distances | IEC 60947-1:2007-06 + A1:2010-12 + A2:2014-09 |
---|---|
Specification | IEC 60947-1:2007-06 + A1:2010-12 + A2:2014-09 |
Minimum clearance - inhomogeneous field (III/3) | 1.5 mm |
Minimum clearance - inhomogeneous field (III/2) | 1.5 mm |
Minimum clearance - inhomogeneous field (II/2) | 1.5 mm |
Minimum creepage distance value (III/3) | 2.5 mm |
Minimum creepage distance value (III/2) | 1.5 mm |
Minimum creepage distance value (II/2) | 2 mm |
Note on connection cross section | With connected conductor 1.5 mm² (solid). |
Specification | IEC 60068-2-6:2007-12 |
---|---|
Result | Test passed |
Frequency | 10 - 150 - 10 Hz |
Sweep speed | 1 octave/min |
Amplitude | 0.35 mm (10 - 60.1 Hz) |
Test duration per axis | 2.5 h |
China RoHS | Environmentally friendly use period: unlimited = EFUP-e |
---|---|
No hazardous substances above threshold values |
eCl@ss 5.1 | 27261100 |
---|---|
eCl@ss 6.0 | 27261100 |
eCl@ss 7.0 | 27440401 |
eCl@ss 8.0 | 27440401 |
eCl@ss 9.0 | 27440401 |
UNSPSC 13.2 | 39121432 |
---|---|
UNSPSC 18.0 | 39121432 |
UNSPSC 19.0 | 39121432 |
UNSPSC 20.0 | 39121432 |
UNSPSC 21.0 | 39121432 |
