> PHOENIX CONTACT >PCB Connectors (PCC)>PTSA 1,5/ 3-3,5-Z 3RZ MIXC 1798087 PHOENIX CONTACT Terminal for printed circuit board, nominal current: 8 A,..
Previous Product Next Product
PTSA 1,5/ 3-3,5-Z 3RZ MIXC 1798087 PHOENIX CONTACT Terminal for printed circuit board, nominal current: 8 A,.. View larger
Images are for illustrative purposes only. Please refer to data sheet for details.

PTSA 1,5/ 3-3,5-Z 3RZ MIXC 1798087 PHOENIX CONTACT Terminal for printed circuit board, nominal current: 8 A,..

PTSA 1,5/ 3-3,5-Z 3RZ MIXC

1798087

PHOENIX_CONTACT

160

Terminal for printed circuit board, nominal current: 8 A, rated voltage: 400 V, pitch: 3.5 mm, number of poles: 3, connection type: spring clamp push-in, mounting: Soldering by wave direction for connection conductor/pcb: 45 °, color: multicolor

PCB terminal block, nominal current: 8 A, rated voltage (III/2): 400 V, nominal cross section: 1.5 mm², pitch: 3.5 mm, number of positions: 3, connection method: Push-in spring connection, mounting: Wave soldering, conductor/PCB connection direction: 45 °, color: multi-color, Pin layout: Zigzag pinning M, Solder pin [P]: 3.6 mm

More details


PCB Connectors (PCC)

* Brand new product in its original packaging covered by the warranties and certifications provided by PHOENIX_CONTACT

Total price: $283.54
Unit price: $1.77

Quantity Price
160+$1.77
320+$1.60
480+$1.53
640+$1.49
*This price is per unit and is the net value (not including taxes if applicable).

If our price is not the best, please ask us for a quote. Ask for a quotation

More info

▲


Key Commercial Data

Orderkey1798087
Packing unit1 pc
Minimum order quantity160 pc
GTIN4046356657624
Weight per Piece (excluding packing)3.000 g
Custom tariff number85369010
Country of originCN (China)

Drawings

Diagram

Diagram
Type: PTSA 1,5/4-3,5-Z
Tested in accordance with DIN EN 60512-5-2:2003-01
Reduction factor = 1
Number of positions: 4

Back to top

Item properties

Brief article descriptionPCB terminal block
Range of articlesPTSA 1,5
Pitch3.5 mm
Number of positions3
Connection methodPush-in spring connection
Mounting typeWave soldering
Pin layoutZigzag pinning M
Number of levels1
Number of connections3
Number of potentials3
Back to top

Electrical parameters

Nominal current8 A
Nom. voltage400 V
Rated voltage250 V
Rated voltage (III/2)400 V
Rated voltage (II/2)630 V
Rated surge voltage (III/3)4 kV
Rated surge voltage (III/2)4 kV
Rated surge voltage (II/2)4 kV
Back to top

Connection capacity

Connection methodPush-in spring connection
pluggableno
Conductor cross section solid0.2 mm² ... 1.5 mm²
Conductor cross section flexible0.2 mm² ... 1.5 mm²
Conductor cross section AWG / kcmil24 ... 16
Conductor cross section flexible, with ferrule without plastic sleeve0.25 mm² ... 1 mm²
Conductor cross section, flexible, with ferrule, with plastic sleeve0.25 mm² ... 0.5 mm²
Stripping length9 mm
Back to top

Material data - contact

NoteWEEE/RoHS-compliant, free of whiskers according to IEC 60068-2-82/JEDEC JESD 201
Contact materialCu alloy
Surface characteristicshot-dip tin-plated
Metal surface terminal point (top layer)Tin (4 - 8 µm Sn)
Metal surface soldering area (top layer)Tin (4 - 8 µm Sn)
Back to top

Material data - housing

Housing colormulti-color
Insulating materialPA
Insulating material groupI
CTI according to IEC 60112600
Flammability rating according to UL 94V0
Glow wire flammability index GWFI according to EN 60695-2-12850
Glow wire ignition temperature GWIT according to EN 60695-2-13775
Temperature for the ball pressure test according to EN 60695-10-2125 °C
Back to top

Dimensions for the product

Dimensional drawing
CaptionThe figure shows the dimensional drawing of the 5-position product version
Length [ l ]12 mm
Width [ w ]22.5 mm
Height [ h ]16.7 mm
Pitch3.5 mm
Height (without solder pin)13.1 mm
Solder pin [P]3.6 mm
Pin spacing3.5 mm
Pin dimensions0.4 x 0.75 mm
Dimension a17.5 mm
Back to top

Dimensions for PCB design

Hole diameter1 mm
Pin spacing3.5 mm
Back to top

Packaging information

Type of packagingpacked in cardboard
Pieces per package160
Denomination packing unitsPcs.
Back to top

Ambient conditions

Ambient temperature (storage/transport)-40 °C ... 70 °C
Ambient temperature (assembly)-5 °C ... 85 °C
Ambient temperature (operation)-40 °C ... 100 °C (Depending on the current carrying capacity/derating curve)
Back to top

Termination and connection method

Test for conductor damage and slackeningIEC 60999-1:1999-11
Test passed
Back to top

Pull-out test

Pull-out testIEC 60999-1:1999-11
Test passed
Conductor cross section / conductor type / tensile force0.5 mm² / solid / > 20 N
0.5 mm² / flexible / > 20 N
1.5 mm² / solid / > 40 N
1.5 mm² / flexible / > 40 N
Back to top

Electrical tests

Rated current8 A
Conductor cross section1.5 mm²
Rated voltage (III/2)400 V
Rated surge voltage (III/2)4 kV
Back to top

Air clearances and creepage distances

Clearances and creepage distancesIEC 60947-1:2007-06 + A1:2010-12 + A2:2014-09
SpecificationIEC 60947-1:2007-06 + A1:2010-12 + A2:2014-09
Minimum clearance - inhomogeneous field (III/3)3 mm
Minimum clearance - inhomogeneous field (III/2)3 mm
Minimum clearance - inhomogeneous field (II/2)3 mm
Minimum creepage distance value (III/3)3.2 mm
Minimum creepage distance value (III/2)3 mm
Minimum creepage distance value (II/2)3.2 mm
Note on connection cross sectionWith connected conductor 1.5 mm² (solid).
Back to top

Temperature-rise test

ResultTest passed
SpecificationIEC 60947-7-4:2013-08
Back to top

Vibration test

SpecificationIEC 60068-2-6:2007-12
ResultTest passed
Frequency10 - 150 - 10 Hz
Sweep speed1 octave/min
Amplitude0.35 mm (10 - 60.1 Hz)
Test duration per axis2.5 h
Back to top

Standards and Regulations

Connection in acc. with standardEN-VDE
Back to top

Environmental Product Compliance

China RoHSEnvironmentally friendly use period: unlimited = EFUP-e
No hazardous substances above threshold values
Back to top

Classifications

eCl@ss

eCl@ss 4.027260700
eCl@ss 4.127141100
eCl@ss 5.027141100
eCl@ss 5.127261100
eCl@ss 6.027261100
eCl@ss 7.027440401
eCl@ss 8.027440401
eCl@ss 9.027440401
Back to top

ETIM

ETIM 3.0EC001121
ETIM 4.0EC002643
ETIM 5.0EC002643
ETIM 6.0EC002643
ETIM 7.0EC002643
Back to top

UNSPSC

UNSPSC 6.0130211801
UNSPSC 7.090139121432
UNSPSC 1134131203
UNSPSC 12.0139121432
UNSPSC 13.239121432
UNSPSC 18.039121432
UNSPSC 19.039121432
UNSPSC 20.039121432
UNSPSC 21.039121432
Back to top

Datasheet - PDF

▲
Title: Size: Type:
PDF CATALOG PHOENIX PCB CONNECTORS EN.pdf 15 Mbytes
