PTSA 1,5/12-3,5-Z MC BD:1-12 Q 1708764 PHOENIX CONTACT PCB terminal block
PTSA 1,5/12-3,5-Z MC BD:1-12 Q
1708764
PHOENIX_CONTACT
80
PCB terminal block
Connectors > Printed circuit board terminal
PCB Connectors (PCC)
* Brand new product in its original packaging covered by the warranties and certifications provided by PHOENIX_CONTACT
More info
▲Dimensions
| Length [ l ] | 12 mm |
|---|---|
| Pitch | 3.5 mm |
| Dimension a | 38.5 mm |
| Width [ w ] | 43.5 mm |
| Height | 13.1 mm |
| Height [ h ] | 16.7 mm |
| Solder pin [P] | 3.6 mm |
| Pin spacing | 3.5 mm |
| Hole diameter | 1 mm |
General
| Range of articles | PTSA 1,5 |
|---|---|
| Nominal current IN | 8 A |
| Nominal cross section | 1.5 mm² |
| Solder pin surface | |
| Number of positions | 12 |
Environmental Product Compliance
| China RoHS | Environmentally friendly use period: unlimited = EFUP-e |
|---|---|
| No hazardous substances above threshold values |
Classifications
