PTDA 2,5/ 5-PH-5,0 MIXED COL 1773772 PHOENIX CONTACT Connector for printed circuit board, nominal current: 1..
PTDA 2,5/ 5-PH-5,0 MIXED COL
1773772
PHOENIX_CONTACT
100
Connector for printed circuit board, nominal current: 14 A, number of poles: 5, pitch: 5 mm, connection type: spring clamp push-in, color: multicolor, surface contacts: Tin
Connector for printed circuit board, nominal section: 2.5 mm², color: multicolor, nominal current: 14 A, nominal voltage (III/2): 400 V, contact surface: Tin, contact type: Female, number of rows: 1, number of poles: 5, family of articles: PTDA 2.5/.. -PH, pitch: 5mm, connection type: Push-in spring connection, driver/printed circuit board connection direction: 45°, plug-in system: COMBICON PST 1.3, lock: without, fixing type: without, packaging type: boxed
PCB Connectors (PCC)
Brand new product in its original packaging covered by the warranties and certifications provided by PHOENIX_CONTACT
Best sellers
▲More info
▲Connector for printed circuit board, number of poles: 5, pitch: 5 mm, color: multicolor
Data commercial
| Key order | One million seven hundred seventy three thousand seven hundred seventy two |
|---|---|
| Packing unit | 100 pcs |
| Key selling | AACHBA - |
| Minimum order quantity | 100 pcs |
| EAN | Four trillion forty six billion three hundred fifty six million four hundred seventy six thousand two hundred sixty three |
| Unit weight (excluding packaging) | 8,345 g |
| Tariff number tariff | Eighty five million three hundred sixty six thousand nine hundred ninety |
| Country of origin | PL (Poland) |
Dimensions
| Length [ l ] | 20 mm |
|---|---|
| Width [ w ] | 26,4 mm |
| Height [ h ] | 16 mm |
| Step | 5 mm |
| Average | 20 mm |
Overview
| Family of articles | PTDA 2,5/..-PH |
|---|---|
| Number of poles | Five |
| Type of connection | Connection by spring loaded push-in |
| Tension and sizing (III/3) | 320 V |
| Connection according to standard | EN-VDE |
| Nominal current IN | 13.5 To |
| Nominal cross section | 2.5 mm2 |
Data connection
| Core cross-section rigid min. | 0,2 mm2 |
|---|---|
| Section of conductor rigid max. | 2.5 mm2 |
| Section of flexible conductor, min. | 0,2 mm2 |
| Section of flexible conductor max. | 2.5 mm2 |
| Section of flexible conductor with toe cap, without plastic sleeve min. | 0.5 mm2 |
| Section of flexible conductor with toe cap, without plastic sleeve max. | 2.5 mm2 |
| Section of flexible conductor with toe, with plastic sleeve min. | 0.5 mm2 |
| Section of flexible conductor with toe, with plastic sleeve max. | 1 mm2 |
| Section of conductor AWG min. | Twenty four |
| Section of conductor AWG max. | Fourteen |
| 2 conductors with same cross section, rigid min. | 0,2 mm2 |
| 2 conductors with same cross section, rigid max. | 2.5 mm2 |
| 2 conductors with same cross section, flexible, min. | 0,2 mm2 |
| 2 conductors with same cross section, flexible max. | 2.5 mm2 |
| 2 conductors with same cross section, flexible with AEH without plastic sleeve min. | 0.5 mm2 |
| 2 conductors with same cross section, flexible with AEH without plastic sleeve max. | 2.5 mm2 |
| 2 conductors with same cross section, flexible with TWIN-AEH with plastic sleeve min. | 0.5 mm2 |
| 2 conductors with same cross section, flexible with TWIN-AEH with plastic sleeve max. | 1 mm2 |
| AWG according to UL/CUL min. | Twenty four |
| AWG according to UL/CUL max. | Fourteen |
Standards and specifications
| Connection according to standard | EN-VDE |
|---|---|
| CUL |
Environmental Product Compliance
| China RoHS | Space of time for the intended use: unlimited = FEUP-e |
|---|---|
| No dangerous substances above the thresholds |
Ratings
eCl@ss
| eCl@ss 4.0 | Twenty seven million one hundred forty one thousand one hundred eleven |
|---|---|
| eCl@ss 4.1 | Twenty seven million one hundred forty one thousand one hundred nine |
| eCl@ss 5.0 | Twenty seven million one hundred forty one thousand one hundred ninety |
| eCl@ss 5.1 | Twenty seven million two hundred sixty thousand seven hundred |
| eCl@ss 6.0 | Twenty seven million two hundred sixty thousand seven hundred |
| eCl@ss 7.0 | Twenty seven million four hundred forty thousand three hundred nine |
| eCl@ss 8.0 | Twenty seven million four hundred forty thousand three hundred nine |
| eCl@ss 9.0 | Twenty seven million four hundred forty thousand three hundred nine |
ETIM
| ETIM 3.0 | EC001121 |
|---|---|
| ETIM 4.0 | EC002643 |
| ETIM 5.0 | EC002638 |
| ETIM 6.0 | EC002638 |
| ETIM 7.0 | EC002638 |
UNSPSC
| UNSPSC 6.01 | Thirty million two hundred eleven thousand eight hundred one |
|---|---|
| UNSPSC 7.0901 | Thirty nine million one hundred twenty one thousand four hundred thirty two |
| UNSPSC 11 | Thirty four million one hundred thirty one thousand two hundred three |
| UNSPSC 12.01 | Thirty nine million one hundred twenty one thousand four hundred thirty two |
| UNSPSC 13.2 | Thirty nine million one hundred twenty one thousand four hundred nine |
| Feature Name | Feature Value |
|---|---|
| Type of connection (EF000064) | Other |
| Contact type (EF001587) | Bus |
| Number of plug-in contact rows (EF006935) | 1 |
| Modular spacing contacts (EF007326) | 5 mm |
| Modular spacing connections (EF006827) | 5 mm |
| Angle contact/conductor connection (EF007546) | Other |
| Rated current In (EF008250) | 13.5 A |
| Rated voltage (EF000228) | 400 V |
| Rated surge voltage (EF002993) | 4 kV |
| Over voltage category (EF006785) | III |
| Pollution degree (EF006786) | 2 |
| Connectable conductor cross section fine-strand without cable end sleeve (EF007341) | 0.2 mm² |
| Connectable conductor cross section fine-strand with cable end sleeve (EF007339) | 0.25 mm² |
| Connectable conductor cross section solid-core (EF007337) | 0.2 mm² |
| Type of electric connection (EF003961) | Spring clamp connection |
| Connectable cable type (EF006816) | Tubular cable |
| Material of contact surface (EF004020) | Tin |
| Material contact (EF007544) | Copper |
| Material insulation body (EF007543) | Polyamide (PA) |
| Housing material (EF001596) | Other |
| Housing colour (EF000136) | Other |
| Inflammability class of insulation material according to UL94 (EF002521) | V0 |
| Operating temperature (EF002393) | -40 °C |
