PT 1,5/ 6-3,5-V (1,3,4,6)BD:NZ 1706642 PHOENIX CONTACT Terminal p. printed circuit board, rated Current: 17,..
PT 1,5/ 6-3,5-V (1,3,4,6)BD:NZ
1706642
PHOENIX_CONTACT
1000
Terminal p. printed circuit board, rated Current: 17,5 A, rated Voltage: 200 V, Pitch: 3.5 mm, Number of poles: 6, Type of connection: Connection by screw with stirrup protection of wire-Mounting: Welding by wave Direction for connection Conductor/pcb: 90 °, Color: green
PCB Connectors (PCC)
Brand new product in its original packaging covered by the warranties and certifications provided by PHOENIX_CONTACT
Best sellers
▲More info
▲Data commercial
| Key order | One million seven hundred six thousand six hundred forty two |
|---|---|
| Packing unit | 250 pcs |
| Key selling | AACAAA - |
| Minimum order quantity | 1000 pcs |
| EAN | Four trillion forty six billion three hundred fifty six million thirty three thousand three hundred ninety eight |
| Unit weight (excluding packaging) | 2,029 g |
| Tariff number tariff | Eighty five million three hundred sixty nine thousand ten |
| Country of origin | (Germany) |
Dimensions
| Length [ l ] | 9 mm |
|---|---|
| Step | 3.5 mm |
| Average | 17.5 mm |
| Height of construction | 7,6 mm |
| Height [ h ] | 7,6 mm |
| Length of pin [P] | 4.5 mm |
| Separation between rods | 3.5 mm |
| Diameter hole | 1.2 mm |
Overview
| Family of articles | PT 1,5/..-V |
|---|---|
| Group insulating material | I |
| Transient voltage design (III/3) | 2.5 kV |
| Transient voltage design (III/2) | 2.5 kV |
| Transient voltage design (II/2) | 2.5 kV |
| Tension and sizing (III/3) | 160 V |
| Tension and sizing (III/2) | 200 V |
| Tension and sizing (II/2) | 400 V |
| Connection according to standard | EN-VDE |
| Nominal current IN | 17,5 To |
| Nominal cross section | 1.5 mm2 |
| Maximum load current | 17,5 To |
| Isolation | PA |
| Surface pin welding | |
| Class of flammability according to UL 94 | V0 |
| Length desaislar | 5 mm |
| Number of poles | Six |
| Screw thread | M2 |
| Tightening torque min. | 0.22 Nm |
| Tightening torque max. | 0,25 Nm |
Data connection
| Section of conductor AWG min. | Twenty six |
|---|---|
| Section of conductor AWG max. | Sixteen |
| 2 conductors with same cross section, rigid min. | 0,2 mm2 |
| 2 conductors with same cross section, rigid max. | 0,34 mm2 |
| 2 conductors with same cross section, flexible, min. | 0,2 mm2 |
| 2 conductors with same cross section, flexible max. | 0.5 mm2 |
Standards and specifications
| Connection according to standard | EN-VDE |
|---|---|
| CUL | |
| Class of flammability according to UL 94 | V0 |
Environmental Product Compliance
| REACh SVHC | Lead 7439-92-1 |
|---|---|
| China RoHS | Space of time for the intended use (FEUP): 50 years |
| You will find information about hazardous substances in the manufacturer's declaration in the "Downloads"tab |
Ratings
eCl@ss 4.0272607xxeCl@ss 4.1Twenty seven million one hundred forty one thousand one hundred nineeCl@ss 5.0Twenty seven million one hundred forty one thousand one hundred ninetyeCl@ss 5.1Twenty seven million two hundred sixty one thousand one hundredeCl@ss 6.0Twenty seven million two hundred sixty one thousand one hundredeCl@ss 7.0Twenty seven million four hundred forty thousand four hundred oneeCl@ss 8.0Twenty seven million four hundred forty thousand four hundred oneeCl@ss 9.0Twenty seven million four hundred forty thousand four hundred one
UNSPSC 6.01Thirty million two hundred eleven thousand eight hundred oneUNSPSC 7.0901Thirty nine million one hundred twenty one thousand four hundred thirty twoUNSPSC 11Thirty four million one hundred thirty one thousand two hundred threeUNSPSC 12.01Thirty nine million one hundred twenty one thousand four hundred thirty twoUNSPSC 13.2Thirty nine million one hundred twenty one thousand four hundred thirty two
