PSM-EG-RS232/TTY-P/2K 2761253 PHOENIX CONTACT Interface converter
PSM-EG-RS232/TTY-P/2K
2761253
PHOENIX_CONTACT
Interface converter
Safety
Brand new product in its original packaging covered by the warranties and certifications provided by PHOENIX_CONTACT
Best sellers
▲More info
▲Key Commercial Data
| Orderkey | 2761253 |
|---|---|
| Packing unit | 1 pc |
| GTIN | 4017918064624 |
| Weight per Piece (excluding packing) | 257.680 g |
| Custom tariff number | 85176200 |
| Country of origin | DE (Germany) |
Note
| Utilization restriction | EMC: class A product, see manufacturer's declaration in the download area |
|---|
General
| Bit delay | ≤ 3 µs |
|---|---|
| Bit distortion | ≤ 5 % |
| Electrical isolation | VCC // V.24 (RS-232) // TTY |
| Test voltage data interfaces | 2.5 kV AC |
| Test voltage data interface/power supply | 2.5 kV AC |
| 2.5 kV | |
| Electromagnetic compatibility | Conformance with EMC Directive 2014/30/EU |
| Noise emission | EN 55022 / Class B |
| Net weight | 257.68 g |
| Housing material | ABS |
| Color | green |
Serial interface
| Interface 1 | V.24 (RS-232) interface in acc. with ITU-T V.28, EIA/TIA-232, DIN 66259-1 |
|---|---|
| Connection method | D-SUB 9 plug |
| Pluggable screw connection | |
| Transmission length | ≤ 15 m (twisted pair) |
| Conductor cross section solid min. | 0.2 mm² |
| Conductor cross section solid max. | 2.5 mm² |
| Conductor cross section flexible min. | 0.2 mm² |
| Conductor cross section flexible max. | 2.5 mm² |
| Conductor cross section AWG min. | 24 |
| Conductor cross section AWG max. | 14 |
| Serial transmission speed | ≤ 19.2 kbps |
| Interface 2 | TTY interface, CL2 in acc. with DIN 66348-1 |
| Operating mode | Active, semi active, passive |
| Connection method | D-SUB-9 female connector |
| Pluggable screw connection | |
| Transmission length | ≤ 1000 m (twisted pair) |
| Conductor cross section flexible min. | 0.2 mm² |
| Conductor cross section flexible max. | 2.5 mm² |
| Conductor cross section AWG min. | 24 |
| Conductor cross section AWG max. | 14 |
| Load/output load current output | ≤ 500 Ω |
| Serial transmission speed | ≤ 19.2 kbps |
Standards and Regulations
| Electromagnetic compatibility | Conformance with EMC Directive 2014/30/EU |
|---|---|
| Noise emission | EN 55022 / Class B |
Environmental Product Compliance
| REACh SVHC | Lead 7439-92-1 |
|---|---|
| China RoHS | Environmentally Friendly Use Period = 50 |
| For details about hazardous substances go to tab “Downloads”, Category “Manufacturer's declaration” |
Classifications
eCl@ss 10.0.119179290eCl@ss 4.027250312eCl@ss 4.127250312eCl@ss 5.027242208eCl@ss 5.127242200eCl@ss 6.019179200eCl@ss 7.019179290eCl@ss 8.019179290eCl@ss 9.019179290
Datasheet - PDF
▲| Title: | Size: | Type: |
|---|---|---|
| PDF CATALOGUE AUTOMATION PHOENIX EN.pdf | 35 Mbytes |
|
