PSM-EG-RS232/RS232-P/4K 2761444 PHOENIX CONTACT Interface converter
PSM-EG-RS232/RS232-P/4K
2761444
PHOENIX_CONTACT
Interface converter
Safety
* Brand new product in its original packaging covered by the warranties and certifications provided by PHOENIX_CONTACT
More info
▲Key Commercial Data
| Orderkey | 2761444 |
|---|---|
| Packing unit | 1 pc |
| Note | Made to Order (non-returnable) |
| GTIN | 4017918064716 |
| Weight per Piece (excluding packing) | 251.050 g |
| Custom tariff number | 85176200 |
| Country of origin | DE (Germany) |
Note
| Utilization restriction | EMC: class A product, see manufacturer's declaration in the download area |
|---|
General
| Bit delay | ≤ 3 µs |
|---|---|
| Bit distortion | ≤ 5 % |
| Electrical isolation | VCC // V.24 (RS-232) (A) // V.24 (RS-232) (B) |
| Test voltage data interfaces | 2.5 kV AC |
| Test voltage data interface/power supply | 2.5 kV AC |
| 2.5 kV | |
| Electromagnetic compatibility | Conformance with EMC Directive 2014/30/EU |
| Net weight | 251.05 g |
| Housing material | ABS |
| Color | green |
Serial interface
| Transmission length | 15 m (twisted pair) |
|---|---|
| Conductor cross section flexible min. | 0.2 mm² |
| Conductor cross section flexible max. | 2.5 mm² |
| Conductor cross section AWG min. | 24 |
| Conductor cross section AWG max. | 14 |
Environmental Product Compliance
| REACh SVHC | Lead 7439-92-1 |
|---|---|
| China RoHS | Environmentally Friendly Use Period = 50 |
| For details about hazardous substances go to tab “Downloads”, Category “Manufacturer's declaration” |
Classifications
eCl@ss 10.0.119179290eCl@ss 4.027250312eCl@ss 4.127250312eCl@ss 5.027242208eCl@ss 5.127242200eCl@ss 6.019179200eCl@ss 7.019179290eCl@ss 8.019179290eCl@ss 9.019179290
Datasheet - PDF
▲| Title: | Size: | Type: |
|---|---|---|
| PDF CATALOG PHOENIX AUTOMATION EN.pdf | 35 Mbytes |
|
