PLH 16/ 2-10-ZB BK 1828853 PHOENIX CONTACT PCB terminal block, nominal current: 76 A, nom. voltage: 1000 V, ..

PLH 16/ 2-10-ZB BK

1828853

PHOENIX_CONTACT

50

PCB terminal block, nominal current: 76 A, nom. voltage: 1000 V, pitch: 10 mm, number of positions: 2, connection method: Push-lock spring connection, mounting: Wave soldering, conductor/PCB connection direction: 0 °, color: black

More details


PCB Connectors (PCC)

* Brand new product in its original packaging covered by the warranties and certifications provided by PHOENIX_CONTACT

* This article may be obsolete. Ask for a quotation and we will check if there are any units available. If not, one of our technicians will look for an alternative solution.

If our price is not the best, please ask us for a quote. Ask for a quotation

Best sellers

▲

More info

▲


PCB terminal block, nominal current: 76 A, nom. voltage: 1000 V, pitch: 10 mm, number of positions: 2, connection method: Push-lock spring connection, mounting: Wave soldering, conductor/PCB connection direction: 0 °, color: black

Key Commercial Data

Orderkey1828853
Packing unit1
GTIN4046356866637
Custom tariff number85369010

Dimensions

Pitch10 mm
Dimension a10 mm
Solder pin [P]4.5 mm
Pin spacing12.5 mm
Hole diameter1.6 mm

General

Range of articlesPLH 16/
Rated surge voltage (III/3)4 kV
Rated surge voltage (III/2)4 kV
Rated surge voltage (II/2)4 kV
Rated voltage (III/3)400 V
Rated voltage (III/2)400 V
Rated voltage (II/2)800 V
Nominal current IN76 A
Nominal cross section16 mm²
Solder pin surface
Stripping length18 mm
Number of positions2

Connection data

Conductor cross section AWG min.18
Conductor cross section AWG max.4
2 conductors with same cross section, stranded, TWIN ferrules with plastic sleeve, min.0.75 mm²
2 conductors with same cross section, stranded, TWIN ferrules with plastic sleeve, max.4 mm²
