PC 6/ 2-ST-10,16 BK 1950285 PHOENIX CONTACT Part plug,nominal Current: 41 A,N. º poles: 2,Pitch: 10,16 mm,th.. View larger
Images are for illustrative purposes only. Please refer to data sheet for details.

PC 6/ 2-ST-10,16 BK 1950285 PHOENIX CONTACT Part plug,nominal Current: 41 A,N. º poles: 2,Pitch: 10,16 mm,th..

PC 6/ 2-ST-10,16 BK

1950285

PHOENIX_CONTACT

50

Part plug,nominal Current: 41 A,N. º poles: 2,Pitch: 10,16 mm,the Technique of connection: Connection by screw with capsule-traction,Color: black,contact Surface: silver

Printed circuit board connector, nominal section: 6 mm2, nominal current: 41 A, nominal voltage (III/2): 1000 V, contact surface: Ag, contact connection type: Female, number of rows: 1, number of poles: 2, family of items: PC 6/.. -ST, pitch: 10.16 mm, connection type: Screw connection with traction capsule, conductor connection direction/printed circuit board: 0 °, clamping hook: - without clamping hook, plug-in system: COMBICON PC 16, locking: without, fixing type: without, packaging type: boxed

More details


PCB Connectors (PCC)

Brand new product in its original packaging covered by the warranties and certifications provided by PHOENIX_CONTACT

* This article may be obsolete. Ask for a quotation and we will check if there are any units available. If not, one of our technicians will look for an alternative solution.

If our price is not the best, please ask us for a quote. Ask for a quotation

Best sellers

More info



Technical data

Item Properties
Product TypePrinted Circuit Board Connector
Product FamilyPC 6/.. -ST
Product LineCOMBICON Connectors L
Number of poles2
Step10.16 mm
Number of rows1
Clamping flangewithout
Data Maintenance Status
Article Review02

Electrical Properties
Nominal Current IN41 A
Nominal voltage UN1000 V
Contact resistance0.5 mΩ
Sizing voltage (III/3)1000 V
Dimensioning transient voltage (III/3)8 kV
Dimensioning voltage (III/2)1000 V
Dimensioning Transient Voltage (III/2)8 kV
Nominal voltage (II/2)1000 V
Dimensioning transient voltage (II/2)6 kV

Connection data
Connection technology
ConstructionStandard
Connector SystemCOMBICON PC 16
Nominal Section6 mm²
Contact Connection TypeFemale
Blockade
Locking systemwithout
Clamping flangewithout
Connecting Conductors
Connection typeScrew connection with traction capsule
Connection Direction Driver/PCB0 °
Rigid conductor section0.75 mm² ... 10 mm²
Flexible conductor section0.75 mm² ... 6 mm²
AWG Conductor Section18 ... 8
Flexible conductor section with toe cap, without plastic sleeve0.5 mm² ... 6 mm²
Flexible conductor section with toe cap, with plastic sleeve0.5 mm² ... 6 mm²
2 conductors with the same cross-section, rigid0.75 mm² ... 4 mm²
2 conductors with the same cross-section, flexible0.75 mm² ... 6 mm²
2 conductors of equal cross-section, flexible with toe cap, without plastic sleeve0.5 mm² ... 2.5 mm²
2 conductors with the same cross-section, flexible with TWIN toe cap with plastic sleeve0.5 mm² ... 4 mm²
Male gauge a x b / Diameter4.3 mm x 4.0 mm / 4.3 mm
Peel Length12 mm
Tightening torque1.2 Nm ... 1.5 Nm

Material Data
Material data - contact
ObservationWEEE/RoHS compliant, filament-free according to IEC 60068-2-82/JEDEC JESD 201
Contact materialCu Alloy
Surface CharacteristicsSelective Coating
Metal surface of the terminal point (top layer)Silver (4 - 8 μm Ag)
Metal surface contact area (top layer)Silver (4 - 8 μm Ag)
Material data - housing
Color ()()
Insulating materialPA
Insulating material groupI
CTI according to IEC 60112600
Flammability class according to UL 94V0
Flammability number of GWFI incandescent filaments according to EN 60695-2-12850
Ignition temperature of incandescent filaments GWIT according to EN 60695-2-13775
Ball hardness test temperature according to EN 60695-10-2125 °C

Dimensions
Dimension Schemeedyvovzxrs.jpg
Step10.16 mm
Overall Height28 mm

Notes
Observation regarding the operationAccording to DIN EN 61984, COMBICON connectors are connectors without switching power (COC). In the event of use as prescribed, they must not be plugged in or unplugged under voltage or under load.

Mechanical testing
Checking for damage to conductors and loosening
Test SpecificationDIN EN 60999-1 (VDE 0609-1):2000-12
ResultApproved Test
Tensile Test
Test SpecificationDIN EN 60999-1 (VDE 0609-1):2000-12
Conductor Section/Conductor Type/Tensile Force Nominal Value/Actual Value0.75 mm² / rigid / > 30 N
0.75 mm² / flexible / > 30 N
10 mm² / rigid / > 90 N
6 mm² / flexible / > 80 N
Forces when plugging in and unplugging
Test SpecificationDIN EN 60512-13-2:2006-11
ResultApproved Test
Number of cycles50
Plug-in force approx.11 N
Power when unplugging by pole approx.14 N
Torque check
Test SpecificationDIN EN 60999-1 (VDE 0609-1):2000-12
Resistance of the signs
Test SpecificationDIN EN 60068-2-70:1996-07
ResultApproved Test
Polarization & Coding
Test SpecificationDIN EN 60512-13-5:2006-11
ResultApproved Test
Eye Exam
Test SpecificationDIN EN 60512-1-1:2003-01
ResultApproved Test
Dimensional Examination
Test SpecificationDIN EN 60512-1-2:2003-01
ResultApproved Test

Environmental and life-life conditions
Vibration test
Test SpecificationDIN EN 60068-2-6 (VDE 0468-2-6):2008-10
frequency10 - 150 - 10 Hz
Sweep speed1 octave/min
Amplitude0.35 mm (10 Hz ... 60.1 Hz)
Acceleration5g (60.1 Hz ... 150 Hz)
Test duration per axis2.5 h
Test DirectionsX, Y, and Z axes
Durability Test
Test SpecificationDIN EN 60512-9-1 (VDE 0687-512-9-1):2010-12
Bearable shock voltage at sea level9.8 kV
Contact Resistance R10.5 mΩ
Contact Resistance R20.4 mΩ
Plug Cycles50
Insulation Resistance Adjacent Poles> 5 MΩ
Climate Essay
Test SpecificationDIN EN ISO 6988:1997-03
Corrosion fatigue0.2 dm3UNDER2in 300 dm3/40 °C/1 cycle
Thermal stress100 °C/168 h
Bearable AC voltage4.26 kV
Environmental conditions
Ambient Temperature (Service)-40 °C ... 100 °C (depending on the rating curve)
Ambient Temperature (Storage/Transport)-40 °C ... 70 °C
Relative humidity of the air (storage/transport)30 % ... 70 %
Ambient Temperature (Mounting)-5 °C ... 100 °C

Electrical Testing
Thermal Test Test Group C
Test SpecificationDIN EN 60512-5-1:2003-01
Number of poles tested9
Insulation resistance
Test SpecificationDIN EN 60512-3-1:2003-01
Insulation Resistance Adjacent Poles> 5 MΩ
Creepage Lines & Air Isolation Distances
Test SpecificationDIN EN 60664-1 (VDE 0110-1):2008-01
Insulating material groupI
Resistance to leakage currents (DIN EN 60112 (VDE 0303-11))CTI 600
Sizing Insulation Voltage (III/3)1000 V
Nominal transient voltage (III/3)8 kV
minimum value of air insulation distance - non-homogeneous field (III/3)8 mm
Minimum creepage line value (III/3)12.5 mm
Sizing Insulation Voltage (III/2)1000 V
Nominal transient voltage (III/2)8 kV
Minimum Value of Air Insulation Distance - Non-Homogeneous Field (III/2)8 mm
Minimum creepage line value (III/2)8 mm
Sizing Insulation Voltage (II/2)1000 V
Nominal transient voltage (II/2)6 kV
Minimum Value of Air Insulation Distance - Non-Homogeneous Field (II/2)5.5 mm
Minimum creepage line value (II/2)5.5 mm

Packaging Information
Type of packagingBoxed Packaging
