PC 6-16/ 6-G1-10,16 BK 1063567 PHOENIX CONTACT Feed-through header PC 6-16/ 6-G1-10,16 BK 1063567
PC 6-16/ 6-G1-10,16 BK
1063567
PHOENIX_CONTACT
50
Feed-through header - PC 6-16/ 6-G1-10,16 BK - 1063567
Connectors > Printed circuit board connector
PCB Connectors (PCC)
* Brand new product in its original packaging covered by the warranties and certifications provided by PHOENIX_CONTACT
More info
▲PCB headers, nominal current: 76 A, rated voltage (III/2): 1000 V, number of positions: 6, pitch: 10.16 mm, color: black, contact surface: Silver, mounting: Wave soldering
Key Commercial Data
| Orderkey | 1063567 |
|---|---|
| Packing unit | 1 |
| GTIN | 4055626719481 |
| Custom tariff number | 85366930 |
Dimensions
| Length [ l ] | 34 mm |
|---|---|
| Width | 64 mm |
| Pitch | 10.16 mm |
| Dimension a | 50.8 mm |
| Width [ w ] | 64 mm |
| Height [ h ] | 17.4 mm |
| Height | 13.4 mm |
| Length of the solder pin | 4 mm |
| Pin dimensions | 1 x 1.2 mm |
| Pin spacing | 1.16 mm |
| Length | 34 mm |
General
| Range of articles | PC 6-16/..-G1 |
|---|---|
| Insulating material | PA |
| Color | black |
| Number of positions | 6 |
Environmental Product Compliance
| China RoHS | Environmentally friendly use period: unlimited = EFUP-e |
|---|---|
| No hazardous substances above threshold values |
Classifications
eCl@ss
| eCl@ss 5.1 | 27260700 |
|---|---|
| eCl@ss 6.0 | 27260700 |
| eCl@ss 7.0 | 27440402 |
| eCl@ss 8.0 | 27440402 |
| eCl@ss 9.0 | 27440402 |
ETIM
| ETIM 5.0 | EC002637 |
|---|---|
| ETIM 6.0 | EC002637 |
| ETIM 7.0 | EC002637 |
Datasheet - PDF
▲| Title: | Size: | Type: |
|---|---|---|
| PDF CATALOG PHOENIX PCB CONNECTORS EN.pdf | 15 Mbytes |
|
