PC 5/ 3-G-7,62 BK 1757413 PHOENIX CONTACT Printed-circuit board connector
PC 5/ 3-G-7,62 BK
1757413
PHOENIX_CONTACT
50
Printed-circuit board connector
PCB base housing, nominal cross-section: 6 mm², colour: black, nominal current: 41 A, nominal voltage (III/2): 630 V, surface contacts: Tin, contact type: Male, number of rows: 1, number of poles: 3, article family: PC 5/.. -G, pitch: 7.62 mm, mounting: Wave soldering, pin arrangement: Linear pin arrangement, pin length [P]: 5 mm, number of solder pins per potential: 3, plug-in system: COMBICON PC 5, Plug-in Face Orientation: Standard, Locking: Without, Attachment Type: Sin, Packing Type: Boxed Packaging
PCB header, nominal cross-section: 6 mm2, colour: black, nominal current: 41 A, reference voltage (III/2): 630 V, contact area: Sn, contact type: Male, number of rows: 1, number of poles: 3, item range: PC 5/.. -G, pitch: 7.62 mm, mounting: Wave welding, spindle plane: Linear pinout, spindle length [P]: 5 mm, number of pins per potential: 3, Plug-in system: COMBICON PC 5, Orientation of the plug-in pattern: Standard, Locking: without, Fastening type: without, Packaging type: packed in a carton
Connectors > Printed circuit board connector
PCB Connectors (PCC)
Brand new product in its original packaging covered by the warranties and certifications provided by PHOENIX_CONTACT
Best sellers
▲More info
▲Key Commercial Data
| Orderkey | 1757413 |
|---|---|
| Packing unit | 50 pc |
| Minimum order quantity | 50 pc |
| GTIN | 4046356342292 |
| Weight per Piece (excluding packing) | 6.660 g |
| Custom tariff number | 85366930 |
| Country of origin | DE (Germany) |
Dimensions
| Length [ l ] | 29.25 mm |
|---|---|
| Width | 25.66 mm |
| Pitch | 7.62 mm |
| Dimension a | 15.24 mm |
| Width [ w ] | 25.66 mm |
| Height [ h ] | 19.29 mm |
| Height | 14.29 mm |
| Length of the solder pin | 5 mm |
| Length | 29.25 mm |
General
| Range of articles | PC 5/..-G |
|---|---|
| Rated voltage (III/3) | 630 V |
| Connection in acc. with standard | EN-VDE |
| Nominal current IN | 41 A |
| Color | black |
| Number of positions | 3 |
Environmental Product Compliance
| China RoHS | Environmentally friendly use period: unlimited = EFUP-e |
|---|---|
| No hazardous substances above threshold values |
Classifications
eCl@ss 4.0272607xxeCl@ss 4.127260701eCl@ss 5.027260701eCl@ss 5.127260700eCl@ss 6.027260700eCl@ss 7.027440402eCl@ss 8.027440402eCl@ss 9.027440402
Datasheet - PDF
▲| Title: | Size: | Type: |
|---|---|---|
| PDF CATALOG PHOENIX PCB CONNECTORS EN.pdf | 27 Mbytes |
|
