NBC-MRD/ 1,0-93K/FSD SCO 1026097 PHOENIX CONTACT Network cable NBC-MRD/ 1,0-93K/FSD SCO 1026097
NBC-MRD/ 1,0-93K/FSD SCO
1026097
PHOENIX_CONTACT
50
Network cable - NBC-MRD/ 1,0-93K/FSD SCO - 1026097
Network cable, Sercos CAT5 (100 Mbps), 4-position, shielded, Plug angled M12 SPEEDCON, coding: D / IP67, on Socket straight M12 SPEEDCON, coding: D / IP67, cable length: 1 m
Industrial Field Connectivity (IFC)
Brand new product in its original packaging covered by the warranties and certifications provided by PHOENIX_CONTACT
Best sellers
▲More info
▲| Product type | Data cable preassembled |
| Sensor type | Sercos |
| Number of positions | 4 |
| Signal type/category | Sercos CAT5, 100 Mbps |
| Nominal voltage UN | 48 V AC |
| 60 V DC |
| Outer sheath, material | PVC |
| Connection 1 | |
| Type | Plug angled M12 SPEEDCON / IP67 |
| Number of positions | 4 |
| Locking type | SPEEDCON |
| Coding type | D (Data) |
| Handle color | black |
| Material | CuSn (Contact) |
| TPU, hardly inflammable, self-extinguishing (Grip body) | |
| Zinc die-cast, nickel-plated (Screw connection) | |
| Insertion/withdrawal cycles | ≥ 100 |
| Insulation resistance | ≥ 100 MΩ |
| Tightening torque | 0.4 Nm |
| Degree of protection | IP67 |
| Ambient temperature (operation) | -25 °C ... 90 °C |
| Connection 2 | |
| Type | Socket straight M12 SPEEDCON / IP67 |
| Number of positions | 4 |
| Locking type | SPEEDCON |
| Coding type | D (Data) |
| Handle color | black |
| Material | CuSn (Contact) |
| Ni/Au (Contact surface) | |
| TPU GF (Contact carriers) | |
| TPU, hardly inflammable, self-extinguishing (Grip body) | |
| Zinc die-cast, nickel-plated (Screw connection) | |
| Insertion/withdrawal cycles | ≥ 100 |
| Insulation resistance | ≥ 100 MΩ |
| Tightening torque | 0.4 Nm |
| Degree of protection | IP67 |
| Ambient temperature (operation) | -25 °C ... 90 °C |
| Cable length | 1 m |
| Signal type/category | Sercos CAT5, 100 Mbps |
| Outer sheath, material | PVC |
| External sheath, color | signal red RAL 3020 |
| Material, inner sheath | PVC |
