MSTBVA 2,5/ 4-G-5,08 THT 1902835 PHOENIX CONTACT Housing base,nominal Current: 12 A,rated Voltage (III/2): 3..
MSTBVA 2,5/ 4-G-5,08 THT
1902835
PHOENIX_CONTACT
50
Housing base,nominal Current: 12 A,rated Voltage (III/2): 320 V,N. º poles: 4,Pitch: 5,08 mm,Color: black,contact Surface: Tin,Assembly: Soldering THR,you will Find more information for the user, and design recommendations on technology, Through Hole Reflow in 'Downloads'
PCB Connectors (PCC)
* Brand new product in its original packaging covered by the warranties and certifications provided by PHOENIX_CONTACT
More info
▲Trade data
| Order Code | One million nine hundred two thousand eight hundred thirty five |
|---|---|
| Packaging unit | 50 pcs |
| Minimum order quantity | 50 pcs |
| Catalogue Page | Page 147 (CC-2002) |
| GTIN | Four trillion seventeen billion nine hundred eighteen million one hundred eighty seven thousand seven hundred forty three |
| Weight per piece (excluding packing) | Of 0.002 KGM |
| Number of the customs tariff | Eighty five million three hundred sixty six thousand nine hundred thirty |
| Country of origin | (Germany) |
Dimensions
| Length [ l ] | The 8.6 mm |
|---|---|
| Width | 22,32 mm |
| Not | 5.08 mm |
| Rated | 15,24 mm |
| Width [ w ] | 22,32 mm |
| Height [ h ] | 15.9 mm |
| Mounting height | 15 mm |
| Length of the picot | 3.9 mm |
| Length | The 8.6 mm |
General
| Family articles | MSTBVA 2,5/..-G-THT |
|---|---|
| Group of insulation | IIIa |
| Impulse voltage assigned (III/3) | 4 kV |
| Impulse voltage assigned (III/2) | 4 kV |
| Impulse voltage assigned to (II/2) | 4 kV |
| Reference voltage (III/3) | 250 V |
| Rated voltage (III/2) | 320 V |
| Rated voltage (II/2) | 400 V |
| Connection according to standard | EN-VDE |
| Rated current IN | Twelve |
| Maximum charge current | Twelve |
| Insulating material | PA |
| Flammability class according to UL 94 | V0 |
| Colours | black |
| Number of poles | Four |
Standards and specifications
| Connection according to standard | EN-VDE |
|---|---|
| ASS | |
| Flammability class according to UL 94 | V0 |
Environmental Product Compliance
| China RoHS | Period of intended use : unlimited = EFUP-e |
|---|---|
| No hazardous substances exceeding the threshold values ; |
Classifications
eCl@ss 4.0272607xxeCl@ss 4.1Twenty seven million two hundred sixty thousand seven hundred oneeCl@ss 5.0Twenty seven million two hundred sixty thousand seven hundred oneeCl@ss 5.1Twenty seven million two hundred sixty thousand seven hundredeCl@ss 6.0Twenty seven million two hundred sixty thousand seven hundredeCl@ss 7.0Twenty seven million four hundred forty thousand four hundred twoeCl@ss 8.0Twenty seven million four hundred forty thousand four hundred twoeCl@ss 9.0Twenty seven million four hundred forty thousand four hundred two
UNSPSC 6.01Thirty million two hundred eleven thousand eight hundred tenUNSPSC 7.0901Thirty nine million one hundred twenty one thousand four hundred nineUNSPSC 11Thirty nine million one hundred twenty one thousand four hundred nineUNSPSC 12.01Thirty nine million one hundred twenty one thousand four hundred nineUNSPSC 13.2Thirty nine million one hundred twenty one thousand four hundred nine
Datasheet - PDF
▲| Title: | Size: | Type: |
|---|---|---|
| PDF CATALOG PHOENIX PCB CONNECTORS EN.pdf | 15 Mbytes |
|
