MSTBA 2,5/ 5-GS-5,08 1998629 PHOENIX CONTACT Housing base,nominal Current: 12 A,rated Voltage (III/2): 320 V..
MSTBA 2,5/ 5-GS-5,08
1998629
PHOENIX_CONTACT
50
Housing base,nominal Current: 12 A,rated Voltage (III/2): 320 V,N. º poles: 5,Pitch: 5,08 mm,Color: green,contact Surface: Tin,Assembly: wave Soldering
PCB Connectors (PCC)
Brand new product in its original packaging covered by the warranties and certifications provided by PHOENIX_CONTACT
Best sellers
▲More info
▲Data commercial
| Key order | One million nine hundred ninety eight thousand six hundred twenty nine |
|---|---|
| Packing unit | 50 pcs |
| Key selling | AAAFDA - |
| Minimum order quantity | 50 pcs |
| EAN | Four trillion seventeen billion nine hundred eighteen million nine hundred sixty five thousand seven hundred sixteen |
| Unit weight (excluding packaging) | 2,162 g |
| Tariff number tariff | Eighty five million three hundred sixty six thousand nine hundred ninety |
| Country of origin | (Germany) |
Dimensions
| Length [ l ] | 12 mm |
|---|---|
| Step | 5,08 mm |
| Average | 20,32 mm |
| Height of construction | 9 mm |
| Length of the pin welding | 3.5 mm |
| Length | 12 mm |
Overview
| Family of articles | MSTBA 2,5/..-GS |
|---|---|
| Group insulating material | IIIa |
| Transient voltage design (III/3) | 4 kV |
| Transient voltage design (III/2) | 4 kV |
| Transient voltage design (II/2) | 4 kV |
| Tension and sizing (III/3) | 250 V |
| Tension and sizing (III/2) | 320 V |
| Tension and sizing (II/2) | 400 V |
| Connection according to standard | EN-VDE |
| Nominal current IN | 12 To |
| Maximum load current | 12 To |
| Isolation | PBT |
| Class of flammability according to UL 94 | V0 |
| Color | green |
| Number of poles | Five |
Standards and specifications
| Connection according to standard | EN-VDE |
|---|---|
| Class of flammability according to UL 94 | V0 |
Environmental Product Compliance
| China RoHS | Space of time for the intended use: unlimited = FEUP-e |
|---|---|
| No dangerous substances above the thresholds |
Ratings
eCl@ss 4.0272607xxeCl@ss 4.1Twenty seven million two hundred sixty thousand seven hundred oneeCl@ss 5.0Twenty seven million two hundred sixty thousand seven hundred oneeCl@ss 5.1Twenty seven million two hundred sixty thousand seven hundredeCl@ss 6.0Twenty seven million two hundred sixty thousand seven hundredeCl@ss 7.0Twenty seven million four hundred forty thousand four hundred twoeCl@ss 8.0Twenty seven million four hundred forty thousand four hundred twoeCl@ss 9.0Twenty seven million four hundred forty thousand four hundred two
UNSPSC 6.01Thirty million two hundred eleven thousand eight hundred tenUNSPSC 7.0901Thirty nine million one hundred twenty one thousand four hundred nineUNSPSC 11Thirty nine million one hundred twenty one thousand four hundred nineUNSPSC 12.01Thirty nine million one hundred twenty one thousand four hundred nineUNSPSC 13.2Thirty nine million one hundred twenty one thousand four hundred nine
Datasheet - PDF
▲| Title: | Size: | Type: |
|---|---|---|
| PDF CATALOG PHOENIX PCB CONNECTORS EN.pdf | 27 Mbytes |
|
