MKDSP 25/ 3-15,00 GY 1761250 PHOENIX CONTACT Terminal p. printed circuit board, nominal Current: 125 A, rate..
MKDSP 25/ 3-15,00 GY
1761250
PHOENIX_CONTACT
25
Terminal p. printed circuit board, nominal Current: 125 A, rated Voltage: 1000 V, Pitch: 15 mm, Number of poles: 3, Type of connection: Connection by screw with capsule-traction, Assembly: Soldering by wave Direction for connection Conductor/pcb: 0 °, Color: grey
PCB Connectors (PCC)
* Brand new product in its original packaging covered by the warranties and certifications provided by PHOENIX_CONTACT
More info
▲Data commercial
| Key order | One million seven hundred sixty one thousand two hundred fifty |
|---|---|
| Packing unit | 25 pcs |
| Key selling | AABFAA - |
| Minimum order quantity | 25 pcs |
| EAN | Four trillion forty six billion three hundred fifty six million three hundred fifty three thousand four hundred forty one |
| Unit weight (excluding packaging) | 62,760 g |
| Tariff number tariff | Eighty five million three hundred sixty nine thousand ten |
| Country of origin | SK (Slovakia) |
Properties of the article
| Abbreviation | Terminal for printed circuit board |
|---|---|
| Family of articles | MKDSP 25 |
| Step | 15 mm |
| Number of poles | Three |
| Type of connection | Connection by screw with capsule-traction |
| Shape of the drive head of screw | Philipps-Recess with lengthwise slot (H1L) |
| Screw thread | M5 |
| Mounting type | Wave soldering |
| Design of the pin | Provision of pins 2x2 linear |
| Number of floors | One |
Characteristic data electrical
| Rated | 125 To |
|---|---|
| Voltage isolation design (III/2) | 1000 V |
| Transient voltage design (III/2) | 8 kV |
Ability conex.
| Section of conductor rigid | 0.5 mm2 ... 35 mm2 |
|---|---|
| Section of flexible conductor | 0.5 mm2 ... 35 mm2 |
| Section of conductor AWG / kcmil | 20 ... 2 |
| Section of flexible conductor with toe cap, without plastic sleeve | 1 mm2 ... 35 mm2 |
| Section of flexible conductor with toe, with padded insulation | 1.5 mm2 ... 35 mm2 |
| 2 conductors with same cross section, rigid | 0.5 mm2 ... 6 mm2 |
| 2 conductors with same cross section, flexible | 0.5 mm2 ... 6 mm2 |
| 2 conductors with same cross section, flexible with AEH without plastic sleeve | 0.5 mm2 ... 4 mm2 |
| 2 conductors with same cross section, flexible with TWIN-AEH with plastic sleeve | 0.5 mm2 ... 16 mm2 |
| Length of peeling | 18 mm |
| Tightening torque | 2.5 Nm ... 4.5 Nm (≤ 25 mm2 = 2.5 Nm; 35 mm2 = 4.5 Nm) |
Material data - contact
| Observation | According to WEEE/RoHS, without filaments according to IEC 60068-2-82/JEDEC JESD 201 |
|---|---|
| Material contact | Cu alloy |
| Characteristics of the surface | tinned galvanically |
| Metal surface of the point of embornaje (top layer) | Tin (5 - 7 µm Sn) |
| Metal surface area of solder (upper layer) | Tin (5 - 7 µm Sn) |
Material data - housing
| Isolation | PA |
|---|---|
| Group insulating material | I |
| CTI according to IEC 60112 | Six hundred |
| Class of flammability according to UL 94 | V0 |
| Number of flammability of filaments GWFI according to en 60695-2-12 | Eight hundred fifty |
| Ignition temperature of filaments GWIT according to en 60695-2-13 | Seven hundred seventy five |
| Temperature test of the hardness for the balls according to en 60695-10-2 | 125 °C |
Product dimensions
| Outline dimensions | |
|---|---|
| Length [ l ] | 31 mm |
| Width [ w ] | 45 mm |
| Height [ h ] | 43.5 mm |
| Step | 15 mm |
| Height of building (height without the shank of soldering) | 39 mm |
| Length of pin [P] | 4.5 mm |
| Dimensions of pin | 1.2 x 1.2 mm |
| Average | 30 mm |
Indications of packing
| Type of packaging | packaged in box |
|---|---|
| Packing unit | Twenty five |
| Designation packing Units | Units |
| Type of outer packaging | Cardboard |
| Default state on delivery | Receptacle terminals open |
Environmental conditions
| Ambient temperature (storage / transport) | -40 °C ... 70 °C |
|---|---|
| Ambient temperature (assembly) | -5 °C ... 100 °C |
| Room temperature (service) | -40 °C |
Connection and method of connection
| Checking of damage in the conductors and loosening | DIN EN 60998-2-1 (VDE 0613-2-1):1994-04 |
|---|---|
| Test approved |
Tensile test
| Tensile test | DIN EN 60998-2-1 (VDE 0613-2-1):1994-04 |
|---|---|
| Test approved | |
| Section of the driver / type of driver / traction force | 0.5 mm2 / rigid / for > 30 N |
| 0.5 mm2 / / flexible > 30 N | |
| 35 mm2 / stiff / > 190 N | |
| 25 mm2 / flexible / > 135 N |
Electrical testing
| Rated | 125 To |
|---|---|
| Voltage isolation design (III/2) | 1000 V |
| Transient voltage design (III/2) | 8 kV |
Lines of flight and air spaces
| Group insulating material | I |
|---|---|
| Voltage | 1000 V |
| Voltage isolation design (III/3) | 1000 V |
| Voltage isolation design (III/2) | 1000 V |
| Voltage isolation design (II/2) | 1000 V |
| Transient voltage design (III/3) | 8 kV |
| Transient voltage design (III/2) | 8 kV |
| Transient voltage design (II/2) | 8 kV |
Test vibration
| Resistance against aging, against moisture, against the entry of solid bodies and against the ingress of detrimental water | Test passed DIN en 60998-2-1 (VDE 0613-2-1):1994-04 168 h/100 °C 48 h/30 °C/92 % |
|---|---|
| The result of the test | Test approved |
| Specification of the test | DIN EN 60998-2-1 (VDE 0613-2-1):1994-04 |
| Dry heat | 168 h/100 °C |
| Moist heat | 48 h/30 °C/92 % |
Resistance to aging, moisture and the penetration of solid objects
| The result of the test | Test approved |
|---|---|
| Specification of the test | DIN EN 60998-2-1 (VDE 0613-2-1):1994-04 |
| Dry heat | 168 h/100 °C |
| Moist heat | 48 h/30 °C/92 % |
Environmental Product Compliance
| China RoHS | Space of time for the intended use: unlimited = FEUP-e |
|---|---|
| No dangerous substances above the thresholds |
Ratings
eCl@ss 4.0Twenty seven million one hundred forty one thousand one hundred eleveneCl@ss 4.1Twenty seven million one hundred forty one thousand one hundred nineeCl@ss 5.0Twenty seven million one hundred forty one thousand one hundred ninetyeCl@ss 5.1Twenty seven million two hundred sixty one thousand one hundredeCl@ss 6.0Twenty seven million two hundred sixty one thousand one hundredeCl@ss 7.0Twenty seven million four hundred forty thousand four hundred oneeCl@ss 8.0Twenty seven million four hundred forty thousand four hundred oneeCl@ss 9.0Twenty seven million four hundred forty thousand four hundred one
UNSPSC 6.01Thirty million two hundred eleven thousand eight hundred oneUNSPSC 7.0901Thirty nine million one hundred twenty one thousand four hundred thirty twoUNSPSC 11Thirty nine million one hundred twenty one thousand four hundred thirty twoUNSPSC 12.01Thirty nine million one hundred twenty one thousand four hundred thirty twoUNSPSC 13.2Thirty nine million one hundred twenty one thousand four hundred thirty two
