MKDSP 10N/ 6-10,16 BK H1L 1864273 PHOENIX CONTACT PCB terminal block, nominal current: 76 A, nom. voltage: 1..
MKDSP 10N/ 6-10,16 BK H1L
1864273
PHOENIX_CONTACT
50
PCB terminal block, nominal current: 76 A, nom. voltage: 1000 V, pitch: 10.16 mm, number of positions: 6, connection method: Screw connection with tension sleeve, mounting: Wave soldering, conductor/PCB connection direction: 0 °, color: black. The article can be aligned to create different nos. of positions!
Terminal block for printed circuit board, nominal current: 76 A, dimensioning voltage (III/2): 1000 V, nominal section: 16 mm², Number of potentials: 6, Number of rows: 1, Number of poles per row: 6, family of articles: MKDSP 10N, pitch: 10.16 mm, type of connection: Screw connection with traction capsule, mounting: Wave soldering, Connection direction conductor/printed circuit board: 0 °, color: black, Pin arrangement: Double linear pin arrangement, Pin length [P]: 5 mm, packaging type: packed in box. The item can be aligned with different numbers of poles!
PCB Connectors (PCC)
Brand new product in its original packaging covered by the warranties and certifications provided by PHOENIX_CONTACT
Best sellers
▲More info
▲PCB terminal block, nominal current: 76 A, nom. voltage: 1000 V, pitch: 10.16 mm, number of positions: 6, connection method: Screw connection with tension sleeve, mounting: Wave soldering, conductor/PCB connection direction: 0 °, color: black. The article can be aligned to create different nos. of positions!
Key Commercial Data
| Orderkey | 1864273 |
|---|---|
| Packing unit | 1 |
| GTIN | 4055626232744 |
| Custom tariff number | 85369010 |
Dimensions
| Length [ l ] | 18.4 mm |
|---|---|
| Pitch | 10.16 mm |
| Dimension a | 50.8 mm |
| Width [ w ] | 60.96 mm |
| Height | 29.3 mm |
| Height [ h ] | 34.3 mm |
| Solder pin [P] | 5 mm |
| Hole diameter | 1.5 mm |
General
| Range of articles | MKDSP 10N |
|---|---|
| Insulating material group | I |
| Rated voltage (III/2) | 1000 V |
| Nominal current IN | 76 A |
| Nominal cross section | 10 mm² |
| Solder pin surface | |
| Flammability rating according to UL 94 | V0 |
| Number of positions | 6 |
| Screw thread | M4 |
Standards and Regulations
| Flammability rating according to UL 94 | V0 |
|---|
Environmental Product Compliance
| REACh SVHC | |
|---|---|
| Lead 7439-92-1 | |
| China RoHS | Environmentally Friendly Use Period = 50 |
| For details about hazardous substances go to tab “Downloads”, Category “Manufacturer's declaration” |
Classifications
eCl@ss
| eCl@ss 5.1 | 27261100 |
|---|---|
| eCl@ss 6.0 | 27261100 |
| eCl@ss 7.0 | 27440401 |
| eCl@ss 8.0 | 27440401 |
| eCl@ss 9.0 | 27440401 |
ETIM
| ETIM 5.0 | EC002643 |
|---|---|
| ETIM 6.0 | EC002643 |
| ETIM 7.0 | EC002643 |
