MKDS 3/17-5,08 BK BDWH:1A-8B 1813376 PHOENIX CONTACT PCB terminal block, nominal current: 24 A, nom. voltage..
MKDS 3/17-5,08 BK BDWH:1A-8B
1813376
PHOENIX_CONTACT
50
PCB terminal block, nominal current: 24 A, nom. voltage: 400 V, pitch: 5.08 mm, number of positions: 17, connection method: Screw connection with tension sleeve, mounting: Wave soldering, conductor/PCB connection direction: 0 °, color: black
PCB terminal block, nominal current: 24 A, rated voltage (III/2): 400 V, nominal cross section: 2.5 mm², pitch: 5.08 mm, number of positions: 17, connection method: Screw connection with tension sleeve, mounting: Wave soldering, conductor/PCB connection direction: 0 °, color: black, Pin layout: Linear pinning, Solder pin [P]: 5 mm
PCB Connectors (PCC)
* Brand new product in its original packaging covered by the warranties and certifications provided by PHOENIX_CONTACT
More info
▲Data commercial
| Key order | One million eight hundred thirteen thousand three hundred seventy six |
|---|---|
| Packing unit | 50 pcs |
| Key selling | AAACAA - |
| Minimum order quantity | 50 pcs |
| EAN | Four trillion forty six billion three hundred fifty six million seven hundred thirty eight thousand two |
| Unit weight (excluding packaging) | 22,220 g |
| Tariff number tariff | Eighty five million three hundred sixty nine thousand ten |
| Country of origin | DE (Germany) |
- Drawings
- Characteristic data electrical
- Material data - contact
- Product dimensions
- Indications of packing
- Environmental conditions
- Tensile test
- Lines of flight and air spaces
- Test vibration
- Standards and specifications
- Ratings
- Properties of the article
- Ability conex.
- Material data - housing
- Dimensions for the design of the printed circuit board
- General indications of product
- Connection and method of connection
- Electrical testing
- Took place. calent.
- Resistance to aging, moisture and the penetration of solid objects
- Environmental Product Compliance
Properties of the article
| Abbreviation | Terminal for printed circuit board |
|---|---|
| Family of articles | MKDS 3 |
| Step | 5,08 mm |
| Number of poles | Seventeen |
| Type of connection | Connection by screw with capsule-traction |
| Shape of the drive head of screw | Lengthwise slot (L) |
| Screw thread | M3 |
| Mounting type | Wave soldering |
| Design of the pin | Available pin linear |
| Number of floors | One |
| Number of connections | Seventeen |
| Number of potential | Seventeen |
Characteristic data electrical
| Rated current | 24 To |
|---|---|
| Rated voltage | 400 V |
| Tension sizing | 250 V |
| Tension and sizing (III/2) | 400 V |
| Tension and sizing (II/2) | 630 V |
| Transient voltage design (III/3) | 4 kV |
| Transient voltage design (III/2) | 4 kV |
| Transient voltage design (II/2) | 4 kV |
Ability conex.
| Type of connection | Connection by screw with capsule-traction |
|---|---|
| plug-in | yes |
| Section of conductor rigid | 0,2 mm2 ... 4 mm2 |
| Section of flexible conductor | 0,2 mm2 ... 2.5 mm2 |
| Section of conductor AWG / kcmil | 24 ... 12 |
| Section of flexible conductor with toe cap, without plastic sleeve | 0.25 mm2 ... 2.5 mm2 |
| Section of flexible conductor with toe, with plastic sleeve | 0.25 mm2 ... 2.5 mm2 |
| 2 conductors with same cross section, rigid | 0,2 mm2 ... 1.5 mm2 |
| 2 conductors with same cross section, flexible | 0,2 mm2 ... 1.5 mm2 |
| 2 conductors of equal section, flexible, with toe cap, without plastic sleeve | 0.25 mm2 ... 0.75 mm2 |
| 2 conductors with same cross section, flexible with toe cap TWIN with plastic sleeve | 0.5 mm2 ... 1.5 mm2 |
| Length of peeling | 8 mm |
| Tightening torque | 0.5 Nm ... 0.6 Nm |
Material data - contact
| Observation | According to WEEE/RoHS, without filaments according to IEC 60068-2-82/JEDEC JESD 201 |
|---|---|
| Material contact | Cu alloy |
| Characteristics of the surface | tinned galvanically |
| Metal surface of the point of embornaje (top layer) | Tin (4 - 8 ám Sn) |
| Metal surface area of solder (upper layer) | Tin (4 - 8 ám Sn) |
Material data - housing
| Color housing | black (9005) |
|---|---|
| Isolation | PA |
| Group insulating material | I |
| CTI according to IEC 60112 | Six hundred |
| Class of flammability according to UL 94 | V0 |
| Number of flammability of filaments GWFI according to en 60695-2-12 | Eight hundred fifty |
| Ignition temperature of filaments GWIT according to en 60695-2-13 | Seven hundred seventy five |
| Temperature test of the hardness for the balls according to en 60695-10-2 | 125 °C |
Product dimensions
| Outline dimensions |  |
|---|---|
| Foot of figure | Figure schematic: for more information see the drawing of the line of products in the download Center |
| Length [ l ] | 11.2 mm |
| Width [ w ] | 86,36 mm |
| Height [ h ] | 23 mm |
| Step | 5,08 mm |
| Height of building (height without the shank of soldering) | 18 mm |
| Length of pin [P] | 5 mm |
| Separation between rods | Of 15.24 mm |
| Dimensions of pin | 0.9 x 0.9 mm |
| Average | 81,28 mm |
Dimensions for the design of the printed circuit board
| Diameter hole | 1.3 mm |
|---|---|
| Separation between rods | Of 15.24 mm |
Indications of packing
| Type of packaging | packaged in box |
|---|---|
| Packing unit | Fifty |
| Designation packing Units | Units |
General indications of product
| Type of observation | Note on the application |
|---|---|
| Observation | For the connection of drivers to safely should always keep a couple of tighten defined. In particular in the terminals for printed circuit board two and three pole, pin and weld individual cannot control it at every point of contact. Therefore, the terminals need help to connect the conductors (fixing manual, support in the box). |
Environmental conditions
| Ambient temperature (storage / transport) | -40 °C ... 70 °C |
|---|---|
| Ambient temperature (assembly) | -5 °C ... 100 °C |
| Room temperature (service) | -40 °C ... 100 °C (depending of the capability curve of a load current/derating) |
Connection and method of connection
| Check connection | DIN EN 60998-2-2 (VDE 0613-2-2):2005-03 |
|---|---|
| Checking of damage in the conductors and loosening | DIN EN 60998-2-1 (VDE 0613-2-1):2005-03 |
| Test approved |
Tensile test
| Tensile test | DIN EN 60998-2-1 (VDE 0613-2-1):2005-03 |
|---|---|
| Test approved | |
| Section of the driver / type of driver / traction force | 0,2 mm2 / stiff / > 10 N |
| 0,2 mm2 / flexible / > 10 N | |
| 4 mm2 / stiff / > 60 N | |
| 2.5 mm2 / flexible / > 50 N |
Electrical testing
| Rated | 24 To |
|---|---|
| Section of driver | 2.5 mm2 |
| Tension and sizing (III/2) | 400 V |
| Transient voltage design (III/2) | 4 kV |
Lines of flight and air spaces
| Air spaces and lines of flight | DIN EN 60947-1 (VDE 0660-100):2015-09 |
|---|---|
| Specification of the test | DIN EN 60947-1 (VDE 0660-100):2015-09 |
| Minimum value of air gap - field inhomogéneo (III/3) | 3 mm |
| Minimum value of air gap - field inhomogéneo (III/2) | 3 mm |
| Minimum value of air gap - field inhomogéneo (II/2) | 3 mm |
| Minimum value of the line of flight (III/3) | 3.2 mm |
| Minimum value of the line of flight (III/2) | 2 mm |
| Minimum value of the line of flight (II/2) | 3.2 mm |
| Warning with respect to the connection section | With the conductor of 4 mm2 (rigid) connected to it. |
Took place. calent.
| Result | Test approved |
|---|---|
| Specification of the test | DIN EN 60998-1 (VDE 0613-1):2005-03 |
Test vibration
| Specification of the test | DIN EN 60068-2-6:1996-05 |
|---|---|
| Result | Test approved |
| Frequency | 10 - 150 - 10 Hz |
| Sweep speed | 1 octave/min |
| Amplitude | 0.35 mm (10 - with 60.1 Hz) |
| Acceleration | 5 g (with 60.1 - 150 Hz) |
| Duration of test per axis | 2.5 h |
Resistance to aging, moisture and the penetration of solid objects
| Dry heat | 168 h/100 °C |
|---|---|
| Moist heat | 48 h/30 °C/92 % |
Environmental Product Compliance
| REACh SVHC | Lead 7439-92-1 |
|---|---|
| China RoHS | Space of time for the intended use (FEUP): 50 years |
| You will find information about hazardous substances in the manufacturer's declaration in the "Downloads"tab |
Ratings
eCl@ss
| eCl@ss 4.0 | Twenty seven million one hundred forty one thousand one hundred nine |
|---|---|
| eCl@ss 4.1 | Twenty seven million one hundred forty one thousand one hundred nine |
| eCl@ss 5.0 | Twenty seven million one hundred forty one thousand one hundred ninety |
| eCl@ss 5.1 | Twenty seven million two hundred sixty one thousand one hundred |
| eCl@ss 6.0 | Twenty seven million two hundred sixty one thousand one hundred |
| eCl@ss 7.0 | Twenty seven million four hundred forty thousand four hundred one |
| eCl@ss 8.0 | Twenty seven million four hundred forty thousand four hundred one |
| eCl@ss 9.0 | Twenty seven million four hundred forty thousand four hundred one |
UNSPSC
| UNSPSC 6.01 | Thirty million two hundred eleven thousand eight hundred one |
|---|---|
| UNSPSC 7.0901 | Thirty nine million one hundred twenty one thousand four hundred thirty two |
| UNSPSC 11 | Thirty nine million one hundred twenty one thousand four hundred thirty two |
| UNSPSC 12.01 | Thirty nine million one hundred twenty one thousand four hundred thirty two |
| UNSPSC 13.2 | Thirty nine million one hundred twenty one thousand four hundred thirty two |
| UNSPSC 18.0 | Thirty nine million one hundred twenty one thousand four hundred thirty two |
| UNSPSC 19.0 | Thirty nine million one hundred twenty one thousand four hundred thirty two |
| UNSPSC 20.0 | Thirty nine million one hundred twenty one thousand four hundred thirty two |
| UNSPSC 21.0 | Thirty nine million one hundred twenty one thousand four hundred thirty two |
