> PHOENIX CONTACT >PCB Connectors (PCC)>MKDS 1,5/ 4-5,08 BK 1800119 PHOENIX CONTACT PCB terminal block, nominal current: 17.5 A, nom. voltage: 400 V..
Previous Product Next Product
MKDS 1,5/ 4-5,08 BK 1800119 PHOENIX CONTACT PCB terminal block, nominal current: 17.5 A, nom. voltage: 400 V.. View larger
Images are for illustrative purposes only. Please refer to data sheet for details.

MKDS 1,5/ 4-5,08 BK 1800119 PHOENIX CONTACT PCB terminal block, nominal current: 17.5 A, nom. voltage: 400 V..

MKDS 1,5/ 4-5,08 BK

1800119

PHOENIX_CONTACT

250

PCB terminal block, nominal current: 17.5 A, nom. voltage: 400 V, pitch: 5.08 mm, number of positions: 4, connection method: Screw connection with tension sleeve, mounting: Wave soldering, conductor/PCB connection direction: 0 °, color: black

PCB terminal block, nominal current: 17.5 A, rated voltage (III/2): 400 V, nominal cross section: 1.5 mm², pitch: 5.08 mm, number of positions: 4, connection method: Screw connection with tension sleeve, mounting: Wave soldering, conductor/PCB connection direction: 0 °, color: black, Pin layout: Linear pinning, Solder pin [P]: 3.5 mm

More details


PCB Connectors (PCC)

* Brand new product in its original packaging covered by the warranties and certifications provided by PHOENIX_CONTACT

Total price: $377.82
Unit price: $1.51

Quantity Price
250+$1.51
500+$1.51
*This price is per unit and is the net value (not including taxes if applicable).

If our price is not the best, please ask us for a quote. Ask for a quotation

More info

▲


Key Commercial Data

Orderkey1800119
Packing unit1 pc
Minimum order quantity250 pc
GTIN4055626056630
Weight per Piece (excluding packing)0.000 g
Custom tariff number85369010
Country of originDE (Germany)

Drawings

Diagram

Diagram
Type: MKDS 1,5/2 and MKDS 1,5/3
Test as per DIN EN 60512-5-2:2003-01
Reduction factor = 1
No. of positions: 5

Back to top

Environmental Product Compliance

REACh SVHCLead 7439-92-1
China RoHSEnvironmentally Friendly Use Period = 50 years
For details about hazardous substances go to tab “Downloads”, Category “Manufacturer's declaration”
Back to top

Classifications

eCl@ss

eCl@ss 5.127261100
eCl@ss 6.027261100
eCl@ss 7.027440401
eCl@ss 8.027440401
eCl@ss 9.027440401
Back to top

ETIM

ETIM 5.0EC002643
ETIM 6.0EC002643
ETIM 7.0EC002643
Back to top

UNSPSC

UNSPSC 13.239121432
UNSPSC 18.039121432
UNSPSC 19.039121432
UNSPSC 20.039121432
UNSPSC 21.039121432
Back to top

Datasheet - PDF

▲
Title: Size: Type:
PDF CATALOG PHOENIX PCB CONNECTORS EN.pdf 15 Mbytes
