MCVR 1,5/ 5-STF-3,5 BK 1748008 PHOENIX CONTACT Part plug,nominal Current: 8 A,N. º poles: 5,Pitch: 3.5 mm,Te..
MCVR 1,5/ 5-STF-3,5 BK
1748008
PHOENIX_CONTACT
50
Part plug,nominal Current: 8 A,N. º poles: 5,Pitch: 3.5 mm,Technique of connection: Connection by screw with capsule-traction,Color: black,contact Surface: Tin
Connectors > Cable connector
PCB Connectors (PCC)
* Brand new product in its original packaging covered by the warranties and certifications provided by PHOENIX_CONTACT
More info
▲Data commercial
| Key order | One million seven hundred forty eight thousand eight |
|---|---|
| Packing unit | 50 pcs |
| Key selling | AAAEBA - |
| Minimum order quantity | 50 pcs |
| EAN | Four trillion forty six billion three hundred fifty six million three hundred thousand fifty six |
| Unit weight (excluding packaging) | 4,584 g |
| Tariff number tariff | Eighty five million three hundred sixty six thousand nine hundred ninety |
| Country of origin | (Germany) |
Overview
| Family of articles | MCVR 1,5/..-STF |
|---|---|
| Number of poles | Five |
| Type of connection | Connection by screw with capsule-traction |
| Tension and sizing (III/3) | 160 V |
| Connection according to standard | EN-VDE |
| Nominal current IN | 8 To |
| Nominal cross section | 1.5 mm2 |
Data connection
| Core cross-section rigid min. | 0.14 mm2 |
|---|---|
| Section of conductor rigid max. | 1.5 mm2 |
| Section of flexible conductor, min. | 0.14 mm2 |
| Section of flexible conductor max. | 1.5 mm2 |
| Section of flexible conductor with toe cap, without plastic sleeve min. | 0.25 mm2 |
| Section of flexible conductor with toe cap, without plastic sleeve max. | 1.5 mm2 |
| Section of flexible conductor with toe, with plastic sleeve min. | 0.25 mm2 |
| Section of flexible conductor with toe, with plastic sleeve max. | 0.5 mm2 |
| Section of conductor AWG min. | Twenty eight |
| Section of conductor AWG max. | Sixteen |
| 2 conductors with same cross section, rigid min. | 0,08 mm2 |
| 2 conductors with same cross section, rigid max. | 0.5 mm2 |
| 2 conductors with same cross section, flexible, min. | 0,08 mm2 |
| 2 conductors with same cross section, flexible max. | 0.75 mm2 |
| 2 conductors with same cross section, flexible with AEH without plastic sleeve min. | 0.25 mm2 |
| 2 conductors with same cross section, flexible with AEH without plastic sleeve max. | 0,34 mm2 |
| 2 conductors with same cross section, flexible with TWIN-AEH with plastic sleeve min. | 0.5 mm2 |
| 2 conductors with same cross section, flexible with TWIN-AEH with plastic sleeve max. | 0.5 mm2 |
| AWG according to UL/CUL min. | Thirty |
| AWG according to UL/CUL max. | Fourteen |
Environmental Product Compliance
| REACh SVHC | Lead 7439-92-1 |
|---|---|
| China RoHS | Space of time for the intended use (FEUP): 50 years |
| You will find information about hazardous substances in the manufacturer's declaration in the "Downloads"tab |
Ratings
eCl@ss 4.0272607xxeCl@ss 4.1Twenty seven million two hundred sixty thousand seven hundred oneeCl@ss 5.0Twenty seven million two hundred sixty thousand seven hundred oneeCl@ss 5.1Twenty seven million two hundred sixty thousand seven hundredeCl@ss 6.0Twenty seven million two hundred sixty thousand seven hundredeCl@ss 7.0Twenty seven million four hundred forty thousand three hundred nineeCl@ss 8.0Twenty seven million four hundred forty thousand three hundred nineeCl@ss 9.0Twenty seven million four hundred forty thousand three hundred nine
UNSPSC 6.01Thirty million two hundred eleven thousand eight hundred tenUNSPSC 7.0901Thirty nine million one hundred twenty one thousand four hundred nineUNSPSC 11Thirty nine million one hundred twenty one thousand four hundred nineUNSPSC 12.01Thirty nine million one hundred twenty one thousand four hundred nineUNSPSC 13.2Thirty nine million one hundred twenty one thousand four hundred nine
Datasheet - PDF
▲| Title: | Size: | Type: |
|---|---|---|
| PDF CATALOG PHOENIX PCB CONNECTORS EN.pdf | 15 Mbytes |
|
