Feed-through header - MCV 1,5/ 5-G-3,81 P14 THRR56 - 1037540

PCB headers, nominal current: 8 A, rated voltage (III/2): 160 V, nominal cross section: 1.5 mm², number of positions: 5, pitch: 3.81 mm, color: black, contact surface: Tin, mounting: THR soldering, pin layout: Linear pinning, solder pin [P]: 1.4 mm

More details


Connectors > Printed circuit board connector

PCB Connectors (PCC)

* Brand new product in its original packaging covered by the warranties and certifications provided by PHOENIX_CONTACT

* This article may be obsolete. Ask for a quotation and we will check if there are any units available. If not, one of our technicians will look for an alternative solution.

If our price is not the best, please ask us for a quote. Ask for a quotation

Best sellers

▲

More info

▲


Key Commercial Data

Orderkey1037540
Packing unit1
GTIN4055626570372
Custom tariff number85366930

Drawings

Diagram

Diagram
Type: FMC 1,5/...-ST-3,81 with MCV 1,5/...-G-3,81 P.. THR

Diagram

Diagram
Type: MC 1,5/...-ST-3,81 with MCV 1,5/...-G-3,81 P26 THR

Diagram

Diagram
Type: FRONT-MC 1,5/...-ST-3,81 with MCV 1,5/...-G-3,81 P...THR

Back to top

Dimensions

Length [ l ]7.25 mm
Width20.44 mm
Pitch3.81 mm
Dimension a15.24 mm
Width [ w ]20.44 mm
Height [ h ]10.6 mm
Height9.2 mm
Length of the solder pin1.4 mm
Pin dimensions0.8 x 0.8 mm
Length7.25 mm
Back to top

General

Range of articlesMCV 1,5/..-G-THR
Colorblack
Number of positions5
