IPC 16/ 4-STGF-10,16 OG 1862644 PHOENIX CONTACT PCB connector, nominal current: 76 A, rated voltage (III/2):..
IPC 16/ 4-STGF-10,16 OG
1862644
PHOENIX_CONTACT
25
PCB connector, nominal current: 76 A, rated voltage (III/2): 1000 V, number of positions: 4, pitch: 10.16 mm, connection method: Screw connection with tension sleeve, color: orange, contact surface: Silver
Connector for printed circuit board, nominal section: 16 mm², color: orange, nominal current: 76 A, dimensioning voltage (III/2): 1000 V, contact surface: silver, contact type: Male, Number of potentials: 4, Number of rows: 1, Number of poles per row: 4, number of connections: 4, family of articles: IPC 16/.. -STGF, pitch: 10.16 mm, connection type: Screw connection with traction capsule, conductor connection direction/printed circuit board: 0 °, Stecksystem: POWER COMBICON 16, Lock: Screw lock, packaging type: boxed
PCB Connectors (PCC)
Brand new product in its original packaging covered by the warranties and certifications provided by PHOENIX_CONTACT
Best sellers
▲More info
▲PCB connector, nominal current: 76 A, rated voltage (III/2): 1000 V, number of positions: 4, pitch: 10.16 mm, connection method: Screw connection with tension sleeve, color: orange, contact surface: Silver
Key Commercial Data
| Orderkey | 1862644 |
|---|---|
| Packing unit | 1 |
| GTIN | 4055626189178 |
| Custom tariff number | 85366990 |
Dimensions
| Length [ l ] | 44.1 mm |
|---|---|
| Width [ w ] | 58.4 mm |
| Height [ h ] | 27.8 mm |
| Pitch | 10.16 mm |
| Dimension a | 30.48 mm |
General
| Range of articles | IPC 16/..-STGF |
|---|---|
| Number of positions | 4 |
| Connection method | Screw connection with tension sleeve |
| Insulating material group | I |
| Rated voltage (III/2) | 1000 V |
| Nominal current IN | 76 A |
| Nominal cross section | 16 mm² |
| Flammability rating according to UL 94 | V0 |
Standards and Regulations
| Flammability rating according to UL 94 | V0 |
|---|
Environmental Product Compliance
| REACh SVHC | |
|---|---|
| Lead 7439-92-1 | |
| China RoHS | Environmentally Friendly Use Period = 50 |
| For details about hazardous substances go to tab “Downloads”, Category “Manufacturer's declaration” |
Classifications
eCl@ss
| eCl@ss 5.1 | 27260700 |
|---|---|
| eCl@ss 6.0 | 27260700 |
| eCl@ss 7.0 | 27440309 |
| eCl@ss 8.0 | 27440309 |
| eCl@ss 9.0 | 27440309 |
ETIM
| ETIM 5.0 | EC002638 |
|---|---|
| ETIM 6.0 | EC002638 |
| ETIM 7.0 | EC002638 |
UNSPSC
| UNSPSC 13.2 | 39121409 |
|---|
Datasheet - PDF
▲| Title: | Size: | Type: |
|---|---|---|
| PDF CATALOG PHOENIX PCB CONNECTORS EN.pdf | 27 Mbytes |
|
