IPC 16/ 3-GF-10,16 GY 1018095 PHOENIX CONTACT Feed-through header IPC 16/ 3-GF-10,16 GY 1018095
IPC 16/ 3-GF-10,16 GY
1018095
PHOENIX_CONTACT
50
Feed-through header - IPC 16/ 3-GF-10,16 GY - 1018095
PCB headers, nominal current: 76 A, rated voltage (III/2): 1000 V, nominal cross section: 16 mm², number of positions: 3, pitch: 10.16 mm, color: gray, contact surface: Silver, mounting: Wave soldering, pin layout: Linear three-way pinning, solder pin [P]: 4 mm
Connectors > Printed circuit board connector
PCB Connectors (PCC)
* Brand new product in its original packaging covered by the warranties and certifications provided by PHOENIX_CONTACT
Best sellers
▲More info
▲Item properties
| Brief article description | Feed-through header |
|---|---|
| Plug-in system | POWER COMBICON 16 |
| Type of contact | Female connector |
| Range of articles | IPC 16/..-GF |
| Pitch | 10.16 mm |
| Number of positions | 3 |
| Mounting type | Wave soldering |
| Pin layout | Linear three-way pinning |
| Number of levels | 1 |
| Number of connections | 3 |
| Number of potentials | 3 |
Electrical parameters
| Nominal current | 76 A |
|---|---|
| Nom. voltage | 1000 V |
| Rated voltage | 1000 V |
| Rated voltage (III/2) | 1000 V |
| Rated voltage (II/2) | 1000 V |
| Rated surge voltage (III/3) | 8 kV |
| Rated surge voltage (III/2) | 8 kV |
| Rated surge voltage (II/2) | 8 kV |
Material data - contact
| Note | WEEE/RoHS-compliant, free of whiskers according to IEC 60068-2-82/JEDEC JESD 201 |
|---|---|
| Contact material | Cu alloy |
| Surface characteristics | |
| Metal surface contact area (top layer) | Silver (4 - 8 µm Ag) |
| Metal surface soldering area (top layer) | Silver (4 - 8 µm Ag) |
Material data - housing
| Housing color | gray (7042) |
|---|---|
| Insulating material | PA |
| Insulating material group | I |
| CTI according to IEC 60112 | 600 |
| Flammability rating according to UL 94 | V0 |
| Glow wire flammability index GWFI according to EN 60695-2-12 | 850 |
| Glow wire ignition temperature GWIT according to EN 60695-2-13 | 775 |
| Temperature for the ball pressure test according to EN 60695-10-2 | 125 °C |
Dimensions for the product
| Dimensional drawing |  |
|---|---|
| Length [ l ] | 32.05 mm |
| Width [ w ] | 48.24 mm |
| Height [ h ] | 17.6 mm |
| Pitch | 10.16 mm |
| Height (without solder pin) | 13.6 mm |
| Solder pin [P] | 4 mm |
| Pin spacing | 10.16 mm |
| Pin dimensions | 0.8 x 1.2 mm |
| Dimension a | 20.32 mm |
Packaging information
| Type of packaging | packed in cardboard |
|---|---|
| Pieces per package | 50 |
| Denomination packing units | Pcs. |
Environmental Product Compliance
| China RoHS | Environmentally friendly use period: unlimited = EFUP-e |
|---|---|
| No hazardous substances above threshold values |
Classifications
eCl@ss
| eCl@ss 4.0 | 27260700 |
|---|---|
| eCl@ss 4.1 | 27260700 |
| eCl@ss 5.0 | 27260700 |
| eCl@ss 5.1 | 27260700 |
| eCl@ss 6.0 | 27260700 |
| eCl@ss 7.0 | 27440402 |
| eCl@ss 8.0 | 27440402 |
| eCl@ss 9.0 | 27440402 |
Datasheet - PDF
▲| Title: | Size: | Type: |
|---|---|---|
| PDF CATALOG PHOENIX PCB CONNECTORS EN.pdf | 15 Mbytes |
|
