GMSTB 2,5 HCV/ 6-ST-7,62RDBD44 1714831 PHOENIX CONTACT Printed-circuit board connector
GMSTB 2,5 HCV/ 6-ST-7,62RDBD44
1714831
PHOENIX_CONTACT
500
Printed-circuit board connector
Connector for printed circuit board, nominal section: 2.5 mm², color: red, nominal current: 16 A, dimensioning voltage (III/2): 1000 V, contact surface: Tin, contact type: Female connection, Number of potentials: 6, Number of rows: 1, Number of poles per row: 6, number of connections: 6, family of articles: GMSTB 2.5 HCV/.. -ST, pitch: 7.62 mm, connection type: Screw connection with traction capsule, conductor connection direction/printed circuit board:0 °, Stecksystem: POWER COMBICON 2.5, Lock: without, packaging type: boxed
Connectors > Cable connector
PCB Connectors (PCC)
Brand new product in its original packaging covered by the warranties and certifications provided by PHOENIX_CONTACT
Best sellers
▲More info
▲PCB connector, nominal current: 16 A, rated voltage (III/2): 1000 V, number of positions: 6, pitch: 7.62 mm, connection method: Screw connection with tension sleeve, color: red, contact surface: Tin
Key Commercial Data
| Orderkey | 1714831 |
|---|---|
| Packing unit | 1 |
| GTIN | 4055626529608 |
| Custom tariff number | 85366990 |
Dimensions
| Length [ l ] | 21 mm |
|---|---|
| Width [ w ] | 45.5 mm |
| Height [ h ] | 17.5 mm |
| Pitch | 7.62 mm |
| Dimension a | 38.1 mm |
General
| Range of articles | GMSTB 2,5 HCV/..-ST |
|---|---|
| Number of positions | 6 |
| Connection method | Screw connection with tension sleeve |
| Nominal cross section | 2.5 mm² |
Environmental Product Compliance
| REACh SVHC | |
|---|---|
| Lead 7439-92-1 | |
| China RoHS | Environmentally Friendly Use Period = 50 |
| For details about hazardous substances go to tab “Downloads”, Category “Manufacturer's declaration” |
Classifications
eCl@ss
| eCl@ss 5.1 | 27260700 |
|---|---|
| eCl@ss 6.0 | 27260700 |
| eCl@ss 7.0 | 27440309 |
| eCl@ss 8.0 | 27440309 |
| eCl@ss 9.0 | 27440309 |
ETIM
| ETIM 5.0 | EC002638 |
|---|---|
| ETIM 6.0 | EC002638 |
| ETIM 7.0 | EC002638 |
Datasheet - PDF
▲| Title: | Size: | Type: |
|---|---|---|
| PDF CATALOG PHOENIX PCB CONNECTORS EN.pdf | 27 Mbytes |
|
