GMSTB 2,5 HC/ 2-STF-7,62
1913390
PHOENIX_CONTACT
50
Printed-circuit board connector
PCB Connectors (PCC)
* Brand new product in its original packaging covered by the warranties and certifications provided by PHOENIX_CONTACT
Thank you for your interest in our products; we hope the delivery time indicated is to your convenience.
While the order is being processed you can select the type of shipment that best suits your needs: 24-hour air express, standard 48-72 hour land, etc.
Orderkey | 1913390 |
---|---|
Packing unit | 50 pc |
Minimum order quantity | 50 pc |
Note | Made to Order (non-returnable) |
GTIN | 4017918192105 |
Weight per Piece (excluding packing) | 3.800 g |
Custom tariff number | 85366990 |
Country of origin | DE (Germany) |
Brief article description | Printed-circuit board connector |
---|---|
Plug-in system | POWER COMBICON 2,5 |
Type of contact | Female connector |
Range of articles | GMSTB 2,5 HC/..-STF |
Pitch | 7.62 mm |
Number of positions | 2 |
Connection method | Screw connection with tension sleeve |
Drive form screw head | Slotted (L) |
Locking | Screw flange |
Number of levels | 1 |
Note | WEEE/RoHS-compliant, free of whiskers according to IEC 60068-2-82/JEDEC JESD 201 |
---|---|
Contact material | Cu alloy |
Surface characteristics | hot-dip tin-plated |
Metal surface terminal point (top layer) | Tin (4 - 8 µm Sn) |
Metal surface contact area (top layer) | Tin (4 - 8 µm Sn) |
Insulating material | PA |
---|---|
CTI according to IEC 60112 | 600 |
Flammability rating according to UL 94 | V0 |
Glow wire flammability index GWFI according to EN 60695-2-12 | 850 |
Glow wire ignition temperature GWIT according to EN 60695-2-13 | 775 |
Temperature for the ball pressure test according to EN 60695-10-2 | 125 °C |
Length [ l ] | 18.2 mm |
---|---|
Width [ w ] | 25.63 mm |
Height [ h ] | 15 mm |
Pitch | 7.62 mm |
Height (without solder pin) | 15 mm |
Dimension a | 7.62 mm |
Type of packaging | packed in cardboard |
---|---|
Pieces per package | 50 |
Denomination packing units | Pcs. |
REACh SVHC | Lead 7439-92-1 |
---|---|
China RoHS | Environmentally Friendly Use Period = 50 |
For details about hazardous substances go to tab “Downloads”, Category “Manufacturer's declaration” |
Title: | Size: | Type: |
---|---|---|
PDF CATALOG PHOENIX PCB CONNECTORS EN.pdf | 15 Mbytes |
