FKCT 2,5/ 3-STF BDWH:1-3 1711780 PHOENIX CONTACT Printed-circuit board connector
FKCT 2,5/ 3-STF BDWH:1-3
1711780
PHOENIX_CONTACT
50
Printed-circuit board connector
Connector for printed circuit board, nominal section: 2.5 mm², color: green, nominal current: 12 A, dimensioning voltage (III/2): 320 V, contact surface: Tin, contact type: Female connection, Number of potentials: 3, Number of rows: 1, Number of poles per row: 3, number of connections: 3, family of articles: FKCT 2.5/.. -STF, pitch: 5mm, connection type: Push-in spring connection, conductor/printed circuit board connection direction: 0°, Stecksystem: CLASSIC COMBICON, Locking: Screw lock, Packaging type: boxed
Connectors > Cable connector
PCB Connectors (PCC)
Brand new product in its original packaging covered by the warranties and certifications provided by PHOENIX_CONTACT
Best sellers
▲More info
▲PCB connector, nominal current: 12 A, rated voltage (III/2): 320 V, number of positions: 3, pitch: 5 mm, connection method: Push-in spring connection, color: green, contact surface: Tin
Key Commercial Data
| Orderkey | 1711780 |
|---|---|
| Packing unit | 1 |
| GTIN | 4055626277837 |
| Custom tariff number | 85366990 |
Dimensions
| Length [ l ] | 25.2 mm |
|---|---|
| Width [ w ] | 25.04 mm |
| Height [ h ] | 15 mm |
| Pitch | 5 mm |
| Dimension a | 10 mm |
General
| Range of articles | FKCT 2,5/..-STF |
|---|---|
| Number of positions | 3 |
| Connection method | Push-in spring connection |
| Rated voltage (III/3) | 320 V |
| Nominal cross section | 2.5 mm² |
Environmental Product Compliance
| China RoHS | Environmentally friendly use period: unlimited = EFUP-e |
|---|---|
| No hazardous substances above threshold values |
Classifications
eCl@ss
| eCl@ss 5.1 | 27260700 |
|---|---|
| eCl@ss 6.0 | 27260700 |
| eCl@ss 7.0 | 27440309 |
| eCl@ss 8.0 | 27440309 |
| eCl@ss 9.0 | 27440309 |
ETIM
| ETIM 5.0 | EC002638 |
|---|---|
| ETIM 6.0 | EC002638 |
| ETIM 7.0 | EC002638 |
Datasheet - PDF
▲| Title: | Size: | Type: |
|---|---|---|
| PDF CATALOG PHOENIX PCB CONNECTORS EN.pdf | 27 Mbytes |
|
