FKCN 2,5/ 5-ST BK 1069360 PHOENIX CONTACT PCB connector FKCN 2,5/ 5-ST BK 1069360
FKCN 2,5/ 5-ST BK
1069360
PHOENIX_CONTACT
50
PCB connector - FKCN 2,5/ 5-ST BK - 1069360
Connectors > Cable connector
PCB Connectors (PCC)
* Brand new product in its original packaging covered by the warranties and certifications provided by PHOENIX_CONTACT
Best sellers
▲More info
▲PCB connector, nominal current: 12 A, rated voltage (III/2): 320 V, number of positions: 5, pitch: 5 mm, connection method: Push-in spring connection, color: black, contact surface: Tin
Key Commercial Data
| Orderkey | 1069360 |
|---|---|
| Packing unit | 1 |
| GTIN | 4055626743974 |
| Custom tariff number | 85366990 |
Dimensions
| Length [ l ] | 27.1 mm |
|---|---|
| Width [ w ] | 25 mm |
| Height [ h ] | 10.9 mm |
| Pitch | 5 mm |
| Dimension a | 20 mm |
General
| Range of articles | FKCN 2,5/..-ST |
|---|---|
| Number of positions | 5 |
| Connection method | Push-in spring connection |
| Nominal cross section | 2.5 mm² |
Environmental Product Compliance
| China RoHS | Environmentally friendly use period: unlimited = EFUP-e |
|---|---|
| No hazardous substances above threshold values |
Classifications
eCl@ss
| eCl@ss 5.1 | 27260700 |
|---|---|
| eCl@ss 6.0 | 27260700 |
| eCl@ss 7.0 | 27440309 |
| eCl@ss 8.0 | 27440309 |
| eCl@ss 9.0 | 27440309 |
ETIM
| ETIM 5.0 | EC002638 |
|---|---|
| ETIM 6.0 | EC002638 |
| ETIM 7.0 | EC002638 |
Datasheet - PDF
▲| Title: | Size: | Type: |
|---|---|---|
| PDF CATALOG PHOENIX PCB CONNECTORS EN.pdf | 15 Mbytes |
|
