FK-MPT 0,5/ 8-3,5-H (VPE1000) 1932193 PHOENIX CONTACT Terminal p. printed circuit board, nominal Current: 4 ..
FK-MPT 0,5/ 8-3,5-H (VPE1000)
1932193
PHOENIX_CONTACT
1000
Terminal p. printed circuit board, nominal Current: 4 A, rated Voltage: 250 V, Pitch: 3.5 mm, Number of poles: 8, Type of connection: spring clamp push-in, Mounting: Soldering by wave Direction for connection Conductor/pcb: 0 °, Color: green
PCB Connectors (PCC)
Brand new product in its original packaging covered by the warranties and certifications provided by PHOENIX_CONTACT
Best sellers
▲More info
▲Data commercial
| Key order | One million nine hundred thirty two thousand one hundred ninety three |
|---|---|
| Packing unit | 1000 pcs |
| Key selling | AACCAA - |
| Minimum order quantity | 1000 pcs |
| EAN | Four trillion seventeen billion nine hundred eighteen million eight hundred fifty three thousand four hundred ninety five |
| Unit weight (excluding packaging) | 3,570 g |
| Tariff number tariff | Eighty five million three hundred sixty nine thousand ten |
| Country of origin | (Germany) |
Dimensions
| Length [ l ] | 9.5 mm |
|---|---|
| Step | 3.5 mm |
| Average | 24,5 mm |
| Width [ w ] | 28.5 mm |
| Height of construction | 8.5 mm |
| Height [ h ] | 12.5 mm |
| Length of pin [P] | 4 mm |
| Separation between rods | 3.5 mm |
| Diameter hole | 1.2 mm |
Overview
| Family of articles | FK-MPT 0,5/..-H |
|---|---|
| Transient voltage design (III/3) | 2.5 kV |
| Transient voltage design (III/2) | 2.5 kV |
| Transient voltage design (II/2) | 2.5 kV |
| Tension and sizing (III/3) | 160 V |
| Tension and sizing (III/2) | 250 V |
| Tension and sizing (II/2) | 250 V |
| Connection according to standard | EN-VDE |
| Nominal current IN | 4 To |
| Nominal cross section | 0.5 mm2 |
| Surface pin welding | |
| Length desaislar | 6.5 mm |
| Number of poles | Eight |
Environmental Product Compliance
| China RoHS | Space of time for the intended use: unlimited = FEUP-e |
|---|---|
| No dangerous substances above the thresholds |
Ratings
eCl@ss 4.0Twenty seven million one hundred forty one thousand one hundred nineeCl@ss 4.1Twenty seven million one hundred forty one thousand one hundred nineeCl@ss 5.0Twenty seven million one hundred forty one thousand one hundred ninetyeCl@ss 5.1Twenty seven million two hundred sixty one thousand one hundredeCl@ss 6.0Twenty seven million two hundred sixty one thousand one hundredeCl@ss 7.0Twenty seven million four hundred forty thousand four hundred oneeCl@ss 8.0Twenty seven million four hundred forty thousand four hundred oneeCl@ss 9.0Twenty seven million four hundred forty thousand four hundred one
UNSPSC 6.01Thirty million two hundred eleven thousand eight hundred oneUNSPSC 7.0901Thirty nine million one hundred twenty one thousand four hundred thirty twoUNSPSC 11Thirty nine million one hundred twenty one thousand four hundred thirty twoUNSPSC 12.01Thirty nine million one hundred twenty one thousand four hundred thirty twoUNSPSC 13.2Thirty nine million one hundred twenty one thousand four hundred thirty two
