FK-MCP 1,5/ 2-STF-3,5 YE 1363503 PHOENIX CONTACT PCB connector, nominal cross-section: 1.5 mm², colour: yell..
FK-MCP 1,5/ 2-STF-3,5 YE
1363503
PHOENIX_CONTACT
1000
PCB connector, nominal cross-section: 1.5 mm², colour: yellow, nominal current: 8 A, nominal voltage (III/2): 160 V, surface contacts: Tin, contact type: Female, number of rows: 1, number of poles: 2, article family: FK-MCP 1.5/.. -STF, pitch: 3.5mm, connection type: Push-in spring connection, conductor/PCB connection direction: 0°, plug-in system: COMBICON MC 1.5, locking: Screw locking, fixing type: Overhead clamping (screw), packing type: boxed packaging
PCB Connectors (PCC)
* Brand new product in its original packaging covered by the warranties and certifications provided by PHOENIX_CONTACT
Related products
▲More info
▲Technical data
Item Properties
| Product Line | COMBICON Connectors S |
| Product Type | Printed Circuit Board Connector |
| Product Family | FK-MCP 1.5/.. -STF |
| Number of poles | 2 |
| Step | 3.5 mm |
| Number of rows | 1 |
Electrical Properties
| Nominal Current IN | 8 A |
| Nominal voltage UN | 160 V |
| Degree of pollution | 3 |
| Contact resistance | 2 mΩ |
| Sizing voltage (III/3) | 160 V |
| Dimensioning transient voltage (III/3) | 2.5 kV |
| Dimensioning voltage (III/2) | 160 V |
| Dimensioning Transient Voltage (III/2) | 2.5 kV |
| Nominal voltage (II/2) | 320 V |
| Dimensioning transient voltage (II/2) | 2.5 kV |
Connection data
| Connection technology | |
| Construction | Standard |
| Connector System | COMBICON MC 1.5 |
| Nominal Section | 1.5 mm² |
| Contact Connection Type | Female |
| Blockade | |
| Locking system | Screw lock |
| Clamping flange | Overhead clamping (screw) |
| Tightening torque | 0.3 Nm |
| Connecting Conductors | |
| Connection type | Push-in spring connection |
| Connection Direction Driver/PCB | 0 ° |
| Rigid conductor section | 0.14 mm² ... 1.5 mm² |
| Flexible conductor section | 0.14 mm² ... 1.5 mm² |
| AWG Conductor Section | 26 ... 16 |
| Flexible conductor section with toe cap, without plastic sleeve | 0.25 mm² ... 1.5 mm² |
| Flexible conductor section with toe cap, with plastic sleeve | 0.25 mm² ... 0.5 mm² |
| Male gauge a x b / Diameter | 2.4 mm x 1.5 mm / - |
| Peel Length | 9 mm |
| Facts about toe caps without an insulated collar | |
| Recommended crimp pliers | 1212034 CRIMPFOX 6 |
| toe caps without insulating collar, according to DIN 46228-1 | Cross-section: 0.25 mm²; Length: 7 mm |
| Cross-section: 0.34 mm²; Length: 7 mm | |
| Cross-section: 0.5 mm²; Length: 8 mm ... 10 mm | |
| Cross-section: 0.75 mm²; Length: 8 mm ... 10 mm | |
| Cross-section: 1 mm²; Length: 8 mm ... 10 mm | |
| Cross-section: 1.5 mm²; Length: 10 mm | |
| Facts about Insulated Collar Toe Caps | |
| Recommended crimp pliers | 1212034 CRIMPFOX 6 |
| toe caps with insulated collar, according to DIN 46228-4 | Cross-section: 0.14 mm²; Length: 8 mm |
| Cross-section: 0.25 mm²; Length: 8 mm | |
| Cross-section: 0.34 mm²; Length: 8 mm | |
| Cross-section: 0.5 mm²; Length: 8 mm ... 10 mm | |
| Cross-section: 0.75 mm²; Length: 10 mm | |
Material Data
| Material data - contact | |
| Observation | WEEE/RoHS compliant, filament-free according to IEC 60068-2-82/JEDEC JESD 201 |
| Contact material | Cu Alloy |
| Surface Characteristics | Malleable cast iron tinning |
| Metal surface of the terminal point (top layer) | Tin (4 - 8 μm Sn) |
| Metal surface contact area (top layer) | Tin (4 - 8 μm Sn) |
| Material data - housing | |
| Color (Housing) | Yellow (1018) |
| Insulating material | PA |
| Insulating material group | I |
| CTI according to IEC 60112 | 600 |
| Flammability class according to UL 94 | V0 |
| Flammability number of GWFI incandescent filaments according to EN 60695-2-12 | 850 |
| Ignition temperature of incandescent filaments GWIT according to EN 60695-2-13 | 775 |
| Ball hardness test temperature according to EN 60695-10-2 | 125 °C |
| Material data: drive element | |
| Insulating material | POM |
| Insulating material group | I |
| CTI according to IEC 60112 | 600 |
| Flammability class according to UL 94 | HB |
Dimensions
| Dimension Scheme |  |
| Step | 3.5 mm |
| Width [w] | 17.3 mm |
| Height [h] | 12.4 mm |
| Length [l] | 20.8 mm |
assembly
| bridle | |
| Tightening torque | 0.3 Nm |
Mechanical testing
| Connecting Conductors | |
| Test Specification | DIN EN 60999-1 (VDE 0609-1):2000-12 |
| Result | Approved Test |
| Checking for damage to conductors and loosening | |
| Test Specification | DIN EN 60999-1 (VDE 0609-1):2000-12 |
| Result | Approved Test |
| Repeated connection and disconnection | |
| Test Specification | DIN EN 60999-1 (VDE 0609-1):2000-12 |
| Result | Approved Test |
| Tensile Test | |
| Test Specification | DIN EN 60999-1 (VDE 0609-1):2000-12 |
| Conductor Section/Conductor Type/Tensile Force Nominal Value/Actual Value | 0.14 mm² / rigid / > 10 N |
| 0.14 mm² / flexible / > 10 N | |
| 1.5 mm² / rigid / > 40 N | |
| 1.5 mm² / flexible / > 40 N | |
| Forces when plugging in and unplugging | |
| Result | Approved Test |
| Number of cycles | 25 |
| Plug-in force approx. | 7 N |
| Power when unplugging by pole approx. | 5 N |
| Resistance of the signs | |
| Test Specification | DIN EN 60068-2-70:1996-07 |
| Result | Approved Test |
| Polarization & Coding | |
| Test Specification | DIN EN 60512-13-5:2006-11 |
| Result | Approved Test |
| Eye Exam | |
| Test Specification | DIN EN 60512-1-1:2003-01 |
| Result | Approved Test |
| Dimensional Examination | |
| Test Specification | DIN EN 60512-1-2:2003-01 |
| Result | Approved Test |
Environmental and life-life conditions
| Vibration test | |
| Test Specification | DIN EN 60068-2-6 (VDE 0468-2-6):2008-10 |
| frequency | 10 - 150 - 10 Hz |
| Sweep speed | 1 octave/min |
| Amplitude | 0.35 mm (10 Hz ... 60.1 Hz) |
| Sweep speed | 5g (60.1 Hz ... 150 Hz) |
| Test duration per axis | 2.5 h |
| Durability Test | |
| Test Specification | DIN IEC 60512-5:1994-05 |
| Bearable shock voltage at sea level | 2.95 kV |
| Contact Resistance R1 | 2 mΩ |
| Contact Resistance R2 | 2.2 mΩ |
| Plug Cycles | 25 |
| Climate Essay | |
| Test Specification | DIN EN ISO 6988:1997-03 |
| Corrosion fatigue | 0.2 dm3UNDER2in 300 dm3/40 °C/1 cycle |
| Thermal stress | 100 °C/168 h |
| Bearable AC voltage | 1.39 kV |
| Crash | |
| Test Specification | DIN EN 60068-2-27 (VDE 0468-2-27):2010-02 |
| Shock Type | Semi-sinusoidal |
| Acceleration | 30g |
| Duration of the crash | 18 ms |
| Test Directions | X, Y, and Z axes (pos. and neg.) |
| Environmental conditions | |
| Ambient Temperature (Service) | -40 °C ... 100 °C (depending on the rating curve) |
| Ambient Temperature (Storage/Transport) | -40 °C ... 70 °C |
| Relative humidity of the air (storage/transport) | 30 % ... 70 % |
| Ambient Temperature (Mounting) | -5 °C ... 100 °C |
Electrical Testing
| Thermal Test | Test Group C | |
| Test Specification | DIN EN 60512-5-1:2003-01 |
| Number of poles tested | 20 |
| Insulation resistance | |
| Test Specification | DIN EN 60512-3-1:2003-01 |
| Insulation Resistance Adjacent Poles | 1012Ω |
| Temperature Cycles | |
| Test Specification | DIN EN 60999-1 (VDE 0609-1):2000-12 |
| Result | Approved Test |
| Creepage Lines & Air Isolation Distances | | |
| Test Specification | DIN EN 60664-1 (VDE 0110-1):2008-01 |
| Insulating material group | I |
| Resistance to leakage currents (DIN EN 60112 (VDE 0303-11)) | CTI 600 |
| Sizing Insulation Voltage (III/3) | 160 V |
| Nominal transient voltage (III/3) | 2.5 kV |
| minimum value of air insulation distance - non-homogeneous field (III/3) | 1.5 mm |
| Minimum creepage line value (III/3) | 2 mm |
| Sizing Insulation Voltage (III/2) | 160 V |
| Nominal transient voltage (III/2) | 2.5 kV |
| Minimum Value of Air Insulation Distance - Non-Homogeneous Field (III/2) | 1.5 mm |
| Minimum creepage line value (III/2) | 1.5 mm |
| Sizing Insulation Voltage (II/2) | 320 V |
| Nominal transient voltage (II/2) | 2.5 kV |
| Minimum Value of Air Insulation Distance - Non-Homogeneous Field (II/2) | 1.5 mm |
| Minimum creepage line value (II/2) | 1.6 mm |
Packaging Information
| Type of packaging | Boxed Packaging |
Datasheet - PDF
▲| Title: | Size: | Type: |
|---|---|---|
| PDF CATALOG PHOENIX PCB CONNECTORS EN.pdf | 15 Mbytes |
|
