FK-MCP 1,5/18-STF-3,81 PRTD 2 5606670 PHOENIX CONTACT PCB connector, nominal current: 8 A, rated voltage (II.. View larger
Images are for illustrative purposes only. Please refer to data sheet for details.

FK-MCP 1,5/18-STF-3,81 PRTD 2 5606670 PHOENIX CONTACT PCB connector, nominal current: 8 A, rated voltage (II..

FK-MCP 1,5/18-STF-3,81 PRTD 2

5606670

PHOENIX_CONTACT

250

PCB connector, nominal current: 8 A, rated voltage (III/2): 160 V, number of positions: 18, pitch: 3.81 mm, connection method: Push-in spring connection, color: green, contact surface: Tin

More details


Connectors > Cable connector

PCB Connectors (PCC)

* Brand new product in its original packaging covered by the warranties and certifications provided by PHOENIX_CONTACT

Total price: $4,670.98
Unit price: $18.68

*This price is per unit and is the net value (not including taxes if applicable).

If our price is not the best, please ask us for a quote. Ask for a quotation

Best sellers

▲

More info

▲


PCB connector, nominal current: 8 A, rated voltage (III/2): 160 V, number of positions: 18, pitch: 3.81 mm, connection method: Push-in spring connection, color: green, contact surface: Tin

Key Commercial Data

Orderkey5606670
Packing unit1
GTIN4055626085067
Custom tariff number85366990

Dimensions

Length [ l ]20.8 mm
Width [ w ]73.3 mm
Height [ h ]12.4 mm
Pitch3.81 mm
Dimension a64.77 mm

General

Range of articlesFK-MCP 1,5/..-ST
Number of positions18
Connection methodPush-in spring connection
Insulating material groupI
Rated voltage (III/2)160 V
Nominal current IN8 A
Nominal cross section1.5 mm²
Flammability rating according to UL 94V0

Specifications for ferrules

Recommended crimping pliers1212034 CRIMPFOX 6
Ferrules without insulating collar, according to DIN 46228‑1Cross section: 0.25 mm²; Length: 7 mm
Cross section: 0.34 mm²; Length: 7 mm
Cross section: 0.5 mm²; Length: 8 mm ... 10 mm
Cross section: 0.75 mm²; Length: 8 mm ... 10 mm
Cross section: 1 mm²; Length: 8 mm ... 10 mm
Cross section: 1.5 mm²; Length: 10 mm

Standards and Regulations

Flammability rating according to UL 94V0

Environmental Product Compliance

China RoHSEnvironmentally friendly use period: unlimited = EFUP-e
No hazardous substances above threshold values

Classifications

eCl@ss

eCl@ss 5.127260700
eCl@ss 6.027260700
eCl@ss 7.027440309
eCl@ss 8.027440309
eCl@ss 9.027440309

ETIM

ETIM 5.0EC002638
ETIM 6.0EC002638
ETIM 7.0EC002638

UNSPSC

UNSPSC 13.239121409

Datasheet - PDF

▲
Title: Size: Type:
PDF CATALOG PHOENIX PCB CONNECTORS EN.pdf 15 Mbytes
