EC 1 12DC/3A S-C 3000756 PHOENIX CONTACT Electronic device circuit breaker
EC 1 12DC/3A S-C
3000756
PHOENIX_CONTACT
Electronic device circuit breaker
Electronic protection switch, ON/OFF control input, rated current: 3 A
Electronic circuit breaker, on/off control input, nominal current: 3 A
Over Current Protection
Brand new product in its original packaging covered by the warranties and certifications provided by PHOENIX_CONTACT
Best sellers
▲More info
▲| Product type | Device circuit breakers |
| Product family | EC-E |
| Type | DIN rail module, one-piece |
| Number of positions | 1 |
| Maximum load current | 3 A (100% duty cycle, 40°C) |
| 3 A (100% duty cycle, 50°C) | |
| Service life electrical | 10000 |
| General | |
| Fuse | electronic |
| Maximum load current | 3 A (100% duty cycle, 40°C) |
| 3 A (100% duty cycle, 50°C) | |
| Line+ / LOAD+ /0V | |
| Screw thread | M4 |
| Tightening torque | 1.5 ... 1.8 Nm |
| Stripping length | 10 mm |
| Conductor cross section rigid | 0.5 mm² ... 10 mm² |
| Conductor cross section flexible | 0.5 mm² ... 10 mm² |
| 2 conductors with same cross section, solid | 0.5 mm² ... 4 mm² |
| 2 conductors with same cross section, flexible | 0.5 mm² ... 4 mm² |
| Nominal current | 3 A |
| Nominal voltage | 12 V DC |
| Signal connections | |
| Screw thread | M3 |
| Tightening torque | 0.5 ... 0.6 Nm |
| Conductor cross section flexible | 0.25 mm² ... 2.5 mm² |
| Width | 12.5 mm |
| Height | 80 mm |
| Color | black (RAL 9005) |
| Ambient conditions | |
| Ambient temperature (operation) | -20 °C ... 60 °C (ordinary locations) |
| Ambient temperature (storage/transport) | -20 °C ... 70 °C |
| Mounting type | DIN rail: 35 mm |
| Feature Name | Feature Value |
|---|---|
| Number of poles (EF001391) | 1 |
| Width (EF000008) | 12.5 mm |
| Height (EF000040) | 80 mm |
| Mounting method (EF000003) | Other |
| Active current limitation x IN (EF011922) | 0 |
| Fuse type (EF011923) | Electronic |
| With remote signalling contact (EF000422) | No |
| Ambient temperature during operating (EF007515) | -20 °C |
Datasheet - PDF
▲| Title: | Size: | Type: |
|---|---|---|
| PDF CATALOG PHOENIX PROTECTION EN.pdf | 27 Mbytes |
|
