E PE A 75X190X56 0899343 PHOENIX CONTACT Junction box
E PE A 75X190X56
0899343
PHOENIX_CONTACT
Junction box
Empty housing, material: Fiberglass-reinforced polyester, squirrel gray RAL 7000, 75 mm x 190 mm x 56 mm, type of closure: Screw-on lid
Empty enclosure, material: Polyester fiberglass reinforced, squirrell grey RAL 7000, 75 mm x 190 mm x 56 mm, type of locking: Screw-on cover
Cabinet enclosures > Enclosure/switchgear cabinet (empty)
Enclosures connectivity
Brand new product in its original packaging covered by the warranties and certifications provided by PHOENIX_CONTACT
Best sellers
▲More info
▲| General | Prepared for direct installation of a DIN rail |
| Product type | Terminal box |
| Type | Empty enclosure with cover |
| Data management status | |
| Article revision | 00 |
| Insulation characteristics | |
| Protection class | II |
| Dimensional drawing |  |
| Width | 75 mm |
| Height | 190 mm |
| Depth | 56 mm |
| Clearance width, maximum DIN rail length | 174 mm |
| max. assembly length | 159 mm |
| Color | squirrell grey RAL 7000 |
| Material | Polyester fiberglass reinforced |
| Flammability rating according to UL 94 | V0 |
| Seal material | Chloroprene |
| Components | halogen-free |
| General | |
| Type of locking (GRP) | Screw-on cover Plus/minus screw |
| Ambient conditions | |
| Ambient temperature (operation) | -40 °C ... 100 °C |
| Assembly note | Integrated blind hole |
| External fixing clips available as an option | |
| Direct DIN rail mounting | yes |
| Useable DIN rail type | NS 15 |
