DFMC 1,5/ 2-ST-3,5 GY 1864710 PHOENIX CONTACT PCB connector, nominal current: 8 A, rated voltage (III/2): 16..
DFMC 1,5/ 2-ST-3,5 GY
1864710
PHOENIX_CONTACT
50
Product on demand only, returns will not be accepted.
PCB connector, nominal current: 8 A, rated voltage (III/2): 160 V, number of positions: 2, pitch: 3.5 mm, connection method: Push-in spring connection, color: gray, contact surface: Tin, AP = anti-rotation pin, at position 1 enlarged drill hole (1.85 mm)
Connector for printed circuit board, nominal section: 1.5 mm², color: gray, nominal current: 8 A, nominal voltage (III/2): 160 V, contact surface: Tin, contact type: Female, number of potentials: 4, number of rows: 2, number of poles: 2, number of connections: 4, article family: DFMC 1.5/.. -ST, pitch: 3.5mm, connection type: Push-in spring connection, driver/printed circuit board connection direction: 0°, plug-in system: COMBICON DFMC 1.5, lock: without, fixing type: without, packaging type: boxed packed, AP=anti-rotation pin, hole raised at position 1 (1.85mm)
Connectors > Cable connector
PCB Connectors (PCC)
Brand new product in its original packaging covered by the warranties and certifications provided by PHOENIX_CONTACT
Best sellers
▲More info
▲Data commercial
| Key order | One million eight hundred sixty four thousand seven hundred ten |
|---|---|
| Packing unit | 50 pcs |
| Key selling | AAAEAF - |
| Minimum order quantity | 50 pcs |
| EAN | Four trillion fifty five billion six hundred twenty six million two hundred sixty five thousand five hundred thirteen |
| Unit weight (excluding packaging) | 2,410 g |
| Tariff number tariff | Eighty five million three hundred sixty six thousand nine hundred ninety |
Back to top
Properties of the article
| Abbreviation | Connector for printed circuit board |
|---|---|
| Plug-in system | MINI COMBICON - DFMC 1,5 |
| Type of contact | Female connection |
| Family of articles | DFMC 1,5/..-ST |
| Step | 3.5 mm |
| Number of poles | Two |
| Type of connection | Connection by spring loaded push-in |
| Number of floors | Two |
| Number of connections | Four |
| Number of potential | Four |
Characteristic data electrical
| Rated current | 8 To |
|---|---|
| Rated voltage | 160 V |
| Tension sizing | 160 V |
| Tension and sizing (III/2) | 160 V |
| Tension and sizing (II/2) | 320 V |
| Transient voltage design (III/3) | 2.5 kV |
| Transient voltage design (III/2) | 2.5 kV |
| Transient voltage design (II/2) | 2.5 kV |
Ability conex.
| Type of connection | Connection by spring loaded push-in |
|---|---|
| plug-in | yes |
| Section of conductor rigid | 0,2 mm2 ... 1.5 mm2 |
| Section of flexible conductor | 0,2 mm2 ... 1.5 mm2 |
| Section of conductor AWG / kcmil | 24 ... 16 |
| Section of flexible conductor with toe cap, without plastic sleeve | 0.25 mm2 ... 1.5 mm2 |
| Section of flexible conductor with toe, with plastic sleeve | 0.14 mm2 ... 0.75 mm2 |
| Length of peeling | 10 mm |
Directions on cutting edge
| Clamp crimp recommended | 1212034 CRIMPFOX 6 |
|---|---|
| Leading without collar is insulated, according to DIN 46228-1 | Section: 0.25 mm2; Length: 7 mm |
| Section: 0,34 mm2; Length: 7 mm | |
| Section: 0.5 mm2; Length: 8 mm ... 10 mm | |
| Section: 0.75 mm2; Length: 8 mm ... 10 mm | |
| Section: 1 mm2; Length: 8 mm ... 10 mm | |
| Section: 1.5 mm2; Length: 10 mm | |
| Clamp crimp recommended | 1212034 CRIMPFOX 6 |
| Leading with collar insulated, according to DIN 46228-4 | Section: 0.14 mm2; Length: 8 mm |
| Section: 0.25 mm2; Length: 8 mm ... 10 mm | |
| Section: 0,34 mm2; Length: 8 mm ... 10 mm | |
| Section: 0.5 mm2; Length: 8 mm ... 10 mm | |
| Section: 0.75 mm2; Length: 10 mm |
Material data - contact
| Observation | According to WEEE/RoHS, without filaments according to IEC 60068-2-82/JEDEC JESD 201 |
|---|---|
| Material contact | Cu alloy |
| Characteristics of the surface | tinning of malleable cast iron |
| Metal surface of the point of embornaje (top layer) | Tin (4 - 8 ám Sn) |
| Metal surface area of contact (top layer) | Tin (4 - 8 ám Sn) |
Material data - housing
| Color housing | grey (7042) |
|---|---|
| Isolation | PA |
| Group insulating material | I |
| CTI according to IEC 60112 | Six hundred |
| Class of flammability according to UL 94 | V0 |
| Number of flammability of filaments GWFI according to en 60695-2-12 | Eight hundred fifty |
| Ignition temperature of filaments GWIT according to en 60695-2-13 | Seven hundred seventy five |
| Temperature test of the hardness for the balls according to en 60695-10-2 | 125 °C |
Material data: drive element
| Isolation | PBT |
|---|---|
| CTI according to IEC 60112 | Six hundred |
| Class of flammability according to UL 94 | V0 |
Product dimensions
| Outline dimensions |  |
|---|---|
| Length [ l ] | 23,35 mm |
| Width [ w ] | 7.8 mm |
| Height [ h ] | 13,25 mm |
| Step | 3.5 mm |
| Height of building (height without the shank of soldering) | 13,25 mm |
| Average | 3.5 mm |
Indications of packing
| Type of packaging | packaged in box |
|---|---|
| Packing unit | Fifty |
| Designation packing Units | Units |
Environmental conditions
| Ambient temperature (storage / transport) | -40 °C ... 70 °C |
|---|---|
| Ambient temperature (assembly) | -5 °C ... 100 °C |
| Room temperature (service) | -40 °C ... 100 °C (in function of the curve derating) |
Connection and method of connection
| Check the connection of conductors | The stripped end of the conductor is the largest you can insert completely and without excessive force, into the opening of the point of embornaje. |
|---|---|
| The result of the test | Test approved |
| Check: connect and drop multiple times | DIN EN 60999-1 (VDE 0609-1):2000-12 |
| Test approved | |
| Checking of damage in the conductors and loosening | DIN EN 60999-1 (VDE 0609-1):2000-12 |
| Test approved |
Tensile test
| Tensile test | DIN EN 60999-1 (VDE 0609-1):2000-12 |
|---|---|
| Test approved | |
| Section of the driver / type of driver / traction force | 0,2 mm2 / stiff / > 10 N |
| 0,2 mm2 / flexible / > 10 N | |
| 1.5 mm2 / stiff / > 40 N | |
| 1,5 mm2 / flexible / > 40 N |
Mechanical testing according to the standards
| Visual Control | Test passed DIN en 60512-1-1:2003-01 |
|---|---|
| Check dimensions | Test passed DIN en 60512-1-2:2003-01 |
| Resistance of prints | Test passed DIN en 60068-2-70:1996-07 |
| Result | Test approved |
| Specification of the test | DIN EN 60512-13-2:2006-11 |
| Number of cycles | Twenty five |
| Force to the plug by polo approx. | 3 N |
| Force when unplugging per pole approx. | 2 N |
| Polarization and coding | Test passed DIN en 60512-13-5:2006-11 |
| Result | Test approved |
| Specification of the test | DIN EN 60512-15-1:2009-03 |
| Strength trial-by-polo | 30 N |
Lines of flight and air spaces
| Air spaces and lines of flight | DIN EN 60664-1 (VDE 0110-1):2008-01 |
|---|---|
| Specification of the test | DIN EN 60664-1 (VDE 0110-1):2008-01 |
| Minimum value of air gap - field inhomogéneo (III/3) | 1.5 mm |
| Minimum value of air gap - field inhomogéneo (III/2) | 1.5 mm |
| Minimum value of air gap - field inhomogéneo (II/2) | 1.5 mm |
| Minimum value of the line of flight (III/3) | 2 mm |
| Minimum value of the line of flight (III/2) | 0.8 mm |
| Minimum value of the line of flight (II/2) | 1.6 mm |
Temperature cycles
| Specification of the test | DIN EN 60999-1 (VDE 0609-1):2000-12 |
|---|---|
| Test current (minimum cross-section) | 4 TO DC |
| Test current (maximum section) | 8 TO DC |
| Temperature cycles | One hundred ninety two |
Mechanical testing (A)
| Force to the plug by polo approx. | 3 N |
|---|---|
| Force when unplugging per pole approx. | 2 N |
| Requirement of impossibility of confusion when connecting >20 N | Test approved |
| Portacontactos used requirement >20 N | Test approved |
Checks resistance (B)
| Specification of the test | DIN EN 60512-9-1 (VDE 0687-512-9-1):2010-12 |
|---|---|
| Contact resistance ROne | 2 mΩ |
| Cycles of plug | Twenty five |
| Contact resistance RTwo | 2,3 mΩ |
| Voltage shock endurable level sea | 2,95 kV |
| Ac voltage bearable | 1,39 kV |
| Insulation resistance Pole-contiguous | > 12 TΩ |
Essays on climate (D)
| Specification of the test | DIN EN ISO 6988:1997-03 |
|---|---|
| Effort cold | -40 °C/2 h |
| Thermal stress | 100 °C/168 h |
| Fatigue corrosion | 0,2 dmThreeSOTwoin 300 dmThree/40 °C/1 cycle |
| Voltage shock endurable level sea | 2,95 kV |
| Ac voltage bearable | 1,39 kV |
Checks and environmental resistance (E)
| Specification of the test | DIN EN 61984 (VDE 0627):2009-11 |
|---|---|
| Result-Degree of protection IP Code | Protection against contact of fingers with finger proof IP20 |
Environmental Product Compliance
| China RoHS | Space of time for the intended use: unlimited = FEUP-e |
|---|---|
| No dangerous substances above the thresholds |
Ratings
eCl@ss
| eCl@ss 4.0 | Twenty seven million two hundred sixty thousand seven hundred |
|---|---|
| eCl@ss 4.1 | Twenty seven million two hundred sixty thousand seven hundred |
| eCl@ss 5.0 | Twenty seven million two hundred sixty thousand seven hundred |
| eCl@ss 5.1 | Twenty seven million two hundred sixty thousand seven hundred |
| eCl@ss 6.0 | Twenty seven million two hundred sixty thousand seven hundred |
| eCl@ss 7.0 | Twenty seven million four hundred forty thousand three hundred nine |
| eCl@ss 8.0 | Twenty seven million four hundred forty thousand three hundred nine |
| eCl@ss 9.0 | Twenty seven million four hundred forty thousand three hundred nine |
| Feature Name | Feature Value |
|---|---|
| Type of connection (EF000064) | Other |
| Contact type (EF001587) | Bus |
| Number of poles (EF001391) | 4 |
| Number of plug-in contact rows (EF006935) | 2 |
| Modular spacing contacts (EF007326) | 3.5 mm |
| Modular spacing connections (EF006827) | 3.5 mm |
| Angle contact/conductor connection (EF007546) | Other |
| Rated current In (EF008250) | 8 A |
| Rated voltage (EF000228) | 160 V |
| Rated surge voltage (EF002993) | 2.5 kV |
| Over voltage category (EF006785) | III |
| Pollution degree (EF006786) | 2 |
| Connectable conductor cross section fine-strand without cable end sleeve (EF007341) | 0.2 mm² |
| Connectable conductor cross section fine-strand with cable end sleeve (EF007339) | 0.14 mm² |
| Connectable conductor cross section solid-core (EF007337) | 0.2 mm² |
| Type of electric connection (EF003961) | Spring clamp connection |
| Connectable cable type (EF006816) | Tubular cable |
| Material of contact surface (EF004020) | Tin |
| Material contact (EF007544) | Copper |
| Material insulation body (EF007543) | Polyamide (PA) |
| Housing material (EF001596) | Other |
| Housing colour (EF000136) | Grey |
| Inflammability class of insulation material according to UL94 (EF002521) | V0 |
| Operating temperature (EF002393) | -40 °C |
