BCVP-500R- 7 GN 5450175 PHOENIX CONTACT Part plug,nominal Current: 12 A,rated Voltage (III/2): 320 V,N. º po..
BCVP-500R- 7 GN
5450175
PHOENIX_CONTACT
50
Part plug,nominal Current: 12 A,rated Voltage (III/2): 320 V,N. º poles: 7,Pitch: 5 mm,Technique of connection: Connection by screw with capsule-traction,Color: whitish green,contact Surface: Tin
PCB Connectors (PCC)
Brand new product in its original packaging covered by the warranties and certifications provided by PHOENIX_CONTACT
Best sellers
▲More info
▲Commercial data
| Ordering code | 5450175 |
|---|---|
| Pieces/pack | 50 PCS |
| Sales key | AAYBAA - |
| Minimum order quantity | 100 PCS |
| GTIN | 4046356840163 |
| Weight per piece (excluding packaging) | 14,699 g |
| Customs Tariff number | 85366990 |
| Country of origin | DE (Germany) |
generality
| Article family | BCVP-R |
|---|---|
| No. of poles | 7 |
| Link | Screw connection with cage |
| Insulation Material Group | The |
| Sizing impulse voltage (III/3) | 4 kV |
| Sizing Impulse Voltage (III/2) | 4 kV |
| Sizing Impulse Voltage (II/2) | 4 kV |
| Sizing voltage (III/3) | 250 V |
| Sizing voltage (III/2) | 320 V |
| Sizing voltage (II/2) | 630 V |
| Rated Current IN | 12 A |
| Nominal cross-section | 2.5 mm² |
| Maximum load current | 12 A (with a conductor cross-section of 2.5 mm²) |
| Insulation material | PA |
| Combustibility class according to UL 94 | V0 |
| Stripping length | 7 mm |
| Thread | M3 |
| Torque min. | 0.5 Nm |
| Max. torque | 0.6 Nm |
Connection data
| Rigid conductor cross-section min. | 0.2 mm² |
|---|---|
| Solid conductor cross-section max. | 2.5 mm² |
| Flexible conductor cross-section min. | 0.2 mm² |
| Flexible conductor cross-section max. | 2.5 mm² |
| Flexible conductor cross-section with cable lug without plastic collar min. | 0.25 mm² |
| Flexible conductor cross-section with cable lug without plastic collar max. | 2.5 mm² |
| Flexible conductor cross-section with cable lug with plastic collar min. | 0.25 mm² |
| Flexible conductor cross-section with cable lug with plastic collar max. | 2.5 mm² |
| Conductor cross-section AWG min. | 24 |
| Conductor cross-section AWG max. | 12 |
| 2 conductors same diameter, rigid min. | 0.2 mm² |
| 2 conductors same diameter, rigid max. | 1 mm² |
| 2 conductors same diameter, flexible min. | 0.2 mm² |
| 2 conductors same diameter, flexible max. | 1.5 mm² |
| 2 conductors with the same diameter, flexible with AEH without plastic collar min. | 0.25 mm² |
| 2 conductors with the same diameter, flexible with AEH without plastic collar max. | 1 mm² |
| 2 conductors with the same diameter, flexible with TWIN-AEH with plastic collar min. | 0.5 mm² |
| 2 conductors with the same diameter, flexible with TWIN-AEH with plastic collar max. | 1.5 mm² |
Regulations and requirements
| Standard-compliant connection | CUL |
|---|---|
| Combustibility class according to UL 94 | V0 |
Environmental Product Compliance
| REACh SVHC | Lead 7439-92-1 |
|---|---|
| China RoHS | Environmentally Friendly Intended Use Period (EFUP): 50 years |
| Information on hazardous substances can be found in the manufacturer's declaration under "Downloads" |
Charts
eCl@ss 4.0Code 272607xxeCl@ss 4.127260701eCl@ss 5.027260701eCl@ss 5.127260700eCl@ss 6.027260700eCl@ss 7.027440309eCl@ss 8.027440309eCl@ss 9.027440309
Datasheet - PDF
▲| Title: | Size: | Type: |
|---|---|---|
| PDF CATALOG PHOENIX PCB CONNECTORS EN.pdf | 27 Mbytes |
|
