BCP-508F- 3 BKBDWH:1-3 1098486 PHOENIX CONTACT PCB connector, nominal current: 12 A, rated voltage (III/2): ..
BCP-508F-3 BKBDWH:1-3
1098486
PHOENIX_CONTACT
1000
Product on demand only, returns will not be accepted.
PCB connector, nominal current: 12 A, rated voltage (III/2): 320 V, nominal cross section: 2.5 mm², number of positions: 3, pitch: 5.08 mm, connection method: Screw connection with tension sleeve, color: black, contact surface: Tin
Connector for printed circuit board, nominal section: 2.5 mm², color: black, nominal current: 12 A, nominal voltage (III/2): 320 V, contact surface: Tin, contact type: Female, number of rows: 1, number of poles: 3, article family: BCP-F, pitch: 5.08 mm, connection type: Screw connection with traction capsule, screw clamping method: H1L Philipps-Recess with longitudinal groove, connection direction conductor/printed circuit board: 0 °, clamping hook: - without clamping hook, plug-in system: BASICLINE 2.5, locking: Screw lock, fixing type: Air clamping (screw), packaging type: boxed
Connectors > Cable connector
PCB Connectors (PCC)
Brand new product in its original packaging covered by the warranties and certifications provided by PHOENIX_CONTACT
Best sellers
▲More info
▲PCB connector, nominal current: 12 A, rated voltage (III/2): 320 V, nominal cross section: 2.5 mm², number of positions: 3, pitch: 5.08 mm, connection method: Screw connection with tension sleeve, color: black, contact surface: Tin
Key Commercial Data
| Orderkey | 1098486 |
|---|---|
| Packing unit | 100 pc |
| Minimum order quantity | 1000 pc |
| Note | Made to Order (non-returnable) |
| GTIN | 4055626943367 |
| Weight per Piece (excluding packing) | 6.100 g |
| Custom tariff number | 85366990 |
| Country of origin | CN (China) |
Datasheet - PDF
▲| Title: | Size: | Type: |
|---|---|---|
| PDF CATALOG PHOENIX PCB CONNECTORS EN.pdf | 27 Mbytes |
|
