BCP-508- 6 BK BDWH:1-6 5454375 PHOENIX CONTACT Part plug, nominal Current: 12 A, Technique of connection: Co..
BCP-508- 6 BK BDWH:1-6
5454375
PHOENIX_CONTACT
100
Part plug, nominal Current: 12 A, Technique of connection: Connection by screw with capsule-traction, Color: black, contact Surface: Tin
Connectors > Cable connector
PCB Connectors (PCC)
Brand new product in its original packaging covered by the warranties and certifications provided by PHOENIX_CONTACT
Best sellers
▲More info
▲Commercial data
| Ordering code | 5454375 |
|---|---|
| Pieces/pack | 100 PCS |
| Sales key | AAYBAA - |
| Minimum order quantity | 100 PCS |
| GTIN | 4046356999793 |
| Weight per piece (excluding packaging) | 10,160 g |
| Customs Tariff number | 85366990 |
generality
| Article family | BCP |
|---|---|
| No. of poles | 6 |
| Link | Screw connection with cage |
| Standard-compliant connection | EN-VDE |
| Rated Current IN | 12 A |
| Nominal cross-section | 2.5 mm² |
Connection data
| Rigid conductor cross-section min. | 0.2 mm² |
|---|---|
| Solid conductor cross-section max. | 2.5 mm² |
| Flexible conductor cross-section min. | 0.2 mm² |
| Flexible conductor cross-section max. | 2.5 mm² |
| Flexible conductor cross-section with cable lug without plastic collar min. | 0.25 mm² |
| Flexible conductor cross-section with cable lug without plastic collar max. | 2.5 mm² |
| Flexible conductor cross-section with cable lug with plastic collar min. | 0.25 mm² |
| Flexible conductor cross-section with cable lug with plastic collar max. | 2.5 mm² |
| Conductor cross-section AWG min. | 24 |
| Conductor cross-section AWG max. | 12 |
| 2 conductors same diameter, rigid min. | 0.2 mm² |
| 2 conductors same diameter, rigid max. | 1 mm² |
| 2 conductors same diameter, flexible min. | 0.2 mm² |
| 2 conductors same diameter, flexible max. | 1.5 mm² |
| 2 conductors with the same diameter, flexible with AEH without plastic collar min. | 0.25 mm² |
| 2 conductors with the same diameter, flexible with AEH without plastic collar max. | 1 mm² |
| 2 conductors with the same diameter, flexible with TWIN-AEH with plastic collar min. | 0.5 mm² |
| 2 conductors with the same diameter, flexible with TWIN-AEH with plastic collar max. | 1.5 mm² |
Environmental Product Compliance
| REACh SVHC | Lead 7439-92-1 |
|---|---|
| China RoHS | Environmentally Friendly Intended Use Period (EFUP): 50 years |
| Information on hazardous substances can be found in the manufacturer's declaration under "Downloads" |
