BCP-508- 3 BK BDWH:-L(+)Q 5455455 PHOENIX CONTACT Part plug, nominal Current: 12 A, Technique of connection:..
BCP-508- 3 BK BDWH:-L(+)Q
5455455
PHOENIX_CONTACT
100
Part plug, nominal Current: 12 A, Technique of connection: Connection by screw with capsule-traction, Color: black, contact Surface: Tin
Connectors > Cable connector
PCB Connectors (PCC)
* Brand new product in its original packaging covered by the warranties and certifications provided by PHOENIX_CONTACT
Best sellers
▲More info
▲Commercial data
| The code for the order | Five million four hundred fifty five thousand four hundred fifty five |
|---|---|
| Pieces/pack. | 100 PCS |
| Sales key | AAYBAA - |
| The amount of minimum order | 100 PCS |
| GTIN | Four trillion forty six billion three hundred fifty six million nine hundred eighty three thousand four hundred thirty three |
| Weight per piece (package included) | 4,500 g |
| Number customs tariff | Eighty five million three hundred sixty six thousand nine hundred ninety |
General
| Family article | BCP |
|---|---|
| N. of poles | Three |
| Link | Screw connection with cage |
| Attack in accordance with | EN-VDE |
| Rated current IN | 12 To |
| Nominal section | 2.5 mm2 |
Data link
| Conductor cross section, rigid min. | 0.2 mm2 |
|---|---|
| Conductor cross section, rigid max. | 2.5 mm2 |
| Conductor cross section flexible min. | 0.2 mm2 |
| Conductor cross section flexible max. | 2.5 mm2 |
| Conductor cross section flexible with crimp connector without collar plastic min. | 0.25 mm2 |
| Conductor cross section flexible with crimp connector without collar plastic max. | 2.5 mm2 |
| Conductor cross section flexible with aeh with collar plastic min. | 0.25 mm2 |
| Conductor cross section flexible with aeh with collar plastic max. | 2.5 mm2 |
| Cross section conductor AWG min. | Twenty four |
| Cross section conductor AWG max. | Twelve |
| 2 conductors with the same diameter, rigid min. | 0.2 mm2 |
| 2 conductors with the same diameter, rigid max. | 1 mm2 |
| 2 conductors with the same diameter, flexible, min. | 0.2 mm2 |
| 2 conductors with the same diameter, flexible, max. | 1.5 mm2 |
| 2 conductors with the same diameter, flexible with AEH without collar plastic min. | 0.25 mm2 |
| 2 conductors with the same diameter, flexible with AEH without collar plastic max. | 1 mm2 |
| 2 conductors with the same diameter, flexible with TWIN-AEH with collar plastic min. | 0.5 mm2 |
| 2 conductors with the same diameter, flexible with TWIN-AEH with collar plastic max. | 1.5 mm2 |
Environmental Product Compliance
| REACh SVHC | Lead 7439-92-1 |
|---|---|
| China RoHS | Period of use conforms to the target without damage to the environment (EFUP): 50 years |
| The information on hazardous substances found in the declaration of the manufacturer under "Downlaods" |
Rankings
eCl@ss 5.1Twenty seven million two hundred sixty thousand seven hundred oneeCl@ss 6.0Twenty seven million two hundred sixty thousand seven hundred fiveeCl@ss 8.0Twenty seven million four hundred forty thousand three hundred nineeCl@ss 9.0Twenty seven million four hundred forty thousand three hundred nine
Datasheet - PDF
▲| Title: | Size: | Type: |
|---|---|---|
| PDF CATALOG PHOENIX PCB CONNECTORS EN.pdf | 15 Mbytes |
|
