BCP-508-15 BK BDWH:I10Q 5455426 PHOENIX CONTACT Part plug, nominal Current: 12 A, Technique of connection: C.. View larger
Images are for illustrative purposes only. Please refer to data sheet for details.

BCP-508-15 BK BDWH:I10Q 5455426 PHOENIX CONTACT Part plug, nominal Current: 12 A, Technique of connection: C..

BCP-508-15 BK BDWH:I10Q

5455426

PHOENIX_CONTACT

100

Available Ship on today

New orders for this item will be processed from April 13

PCB connector

More details


PCB Connectors (PCC)

* Brand new product in its original packaging covered by the warranties and certifications provided by PHOENIX_CONTACT

Quantity Price
100+$8.09
200+$8.02
*This price is per unit and is the net value (not including taxes if applicable).

If our price is not the best, please ask us for a quote. Ask for a quotation

More info



Key Commercial Data

Orderkey 5455426
Packing unit 100 pc
Minimum order quantity500 pc
NoteMade to Order (non-returnable)
GTIN4046356983402
Weight per Piece (excluding packing)26.520 g
Custom tariff number85366990
Country of originCN (China)

Dimensions

Length [ l ]18.2 mm
Width [ w ]76.2 mm
Height [ h ]15 mm
Pitch5.08 mm
Dimension a71.12 mm

General

Range of articlesBCP
Number of positions15
Connection methodScrew connection with tension sleeve
Connection in acc. with standardEN-VDE
Nominal current IN12 A
Nominal cross section2.5 mm²

Connection data

Conductor cross section solid min.0.2 mm²
Conductor cross section solid max.2.5 mm²
Conductor cross section flexible min.0.2 mm²
Conductor cross section flexible max.2.5 mm²
Conductor cross section flexible, with ferrule without plastic sleeve min.0.25 mm²
Conductor cross section flexible, with ferrule without plastic sleeve max.2.5 mm²
Conductor cross section flexible, with ferrule with plastic sleeve min.0.25 mm²
Conductor cross section flexible, with ferrule with plastic sleeve max.2.5 mm²
Conductor cross section AWG min.24
Conductor cross section AWG max.12
2 conductors with same cross section, solid min.0.2 mm²
2 conductors with same cross section, solid max.1 mm²
2 conductors with same cross section, stranded min.0.2 mm²
2 conductors with same cross section, stranded max.1.5 mm²
2 conductors with same cross section, stranded, ferrules without plastic sleeve, min.0.25 mm²
2 conductors with same cross section, stranded, ferrules without plastic sleeve, max.1 mm²
2 conductors with same cross section, stranded, TWIN ferrules with plastic sleeve, min.0.5 mm²
2 conductors with same cross section, stranded, TWIN ferrules with plastic sleeve, max.1.5 mm²

Standards and Regulations

Connection in acc. with standardEN-VDE

Environmental Product Compliance

REACh SVHCLead 7439-92-1
China RoHSEnvironmentally Friendly Use Period = 50
For details about hazardous substances go to tab “Downloads”, Category “Manufacturer's declaration”
