BCP-500F-13 GN
5448556
PHOENIX_CONTACT
100
Printed-circuit board connector
PCB connector, nominal current: 12 A, rated voltage (III/2): 320 V, nominal cross section: 2.5 mm², number of positions: 13, pitch: 5 mm, connection method: Screw connection with tension sleeve, color: pastel green, contact surface: Tin
Connectors > Cable connector
PCB Connectors (PCC)
* Brand new product in its original packaging covered by the warranties and certifications provided by PHOENIX_CONTACT
Thank you for your interest in our products; we hope the delivery time indicated is to your convenience.
While the order is being processed you can select the type of shipment that best suits your needs: 24-hour air express, standard 48-72 hour land, etc.
Orderkey | 5448556 |
---|---|
Packing unit | 1 pc |
Minimum order quantity | 100 pc |
GTIN | 4046356837996 |
Weight per Piece (excluding packing) | 0.000 g |
Custom tariff number | 85366990 |
Country of origin | CN (China) |
Length [ l ] | 18.2 mm |
---|---|
Width [ w ] | 74.94 mm |
Height [ h ] | 15 mm |
Pitch | 5 mm |
Dimension a | 60 mm |
Range of articles | BCP-F |
---|---|
Number of positions | 13 |
Connection method | Screw connection with tension sleeve |
Insulating material group | I |
Rated surge voltage (III/3) | 4 kV |
Rated surge voltage (III/2) | 4 kV |
Rated surge voltage (II/2) | 4 kV |
Rated voltage (III/3) | 250 V |
Rated voltage (III/2) | 320 V |
Rated voltage (II/2) | 630 V |
Nominal current IN | 12 A |
Nominal cross section | 2.5 mm² |
Maximum load current | 12 A (with a 2.5 mm² conductor cross section) |
Insulating material | PA |
Flammability rating according to UL 94 | V0 |
Stripping length | 7 mm |
Screw thread | M3 |
Tightening torque, min | 0.4 Nm |
Tightening torque max | 0.5 Nm |
Conductor cross section solid min. | 0.2 mm² |
---|---|
Conductor cross section solid max. | 2.5 mm² |
Conductor cross section flexible min. | 0.2 mm² |
Conductor cross section flexible max. | 2.5 mm² |
Conductor cross section flexible, with ferrule without plastic sleeve min. | 0.25 mm² |
Conductor cross section flexible, with ferrule without plastic sleeve max. | 2.5 mm² |
Conductor cross section flexible, with ferrule with plastic sleeve min. | 0.25 mm² |
Conductor cross section flexible, with ferrule with plastic sleeve max. | 2.5 mm² |
Conductor cross section AWG min. | 24 |
Conductor cross section AWG max. | 12 |
2 conductors with same cross section, solid min. | 0.2 mm² |
2 conductors with same cross section, solid max. | 1 mm² |
2 conductors with same cross section, stranded min. | 0.2 mm² |
2 conductors with same cross section, stranded max. | 1.5 mm² |
Two conductors with the same cross section stranded, with ferrule and without plastic sleeve, minimum | 0.25 mm² |
Two conductors with the same cross section stranded, with ferrule and without plastic sleeve, maximum | 1 mm² |
Two conductors with the same cross section, flexible, with TWIN ferrules, with plastic sleeve, minimum | 0.5 mm² |
Two conductors with the same cross section, flexible, with TWIN ferrules, with plastic sleeve, maximum | 1.5 mm² |
Connection in acc. with standard | CUL |
---|---|
Flammability rating according to UL 94 | V0 |
REACh SVHC | Lead 7439-92-1 |
---|---|
China RoHS | Environmentally Friendly Use Period = 50 years |
For details about hazardous substances go to tab “Downloads”, Category “Manufacturer's declaration” |
eCl@ss 4.0 | 27260700 |
---|---|
eCl@ss 4.1 | 27260700 |
eCl@ss 5.0 | 27260700 |
eCl@ss 5.1 | 27260700 |
eCl@ss 6.0 | 27260700 |
eCl@ss 7.0 | 27440309 |
eCl@ss 8.0 | 27440309 |
eCl@ss 9.0 | 27440309 |
UNSPSC 6.01 | 30211801 |
---|---|
UNSPSC 7.0901 | 39121432 |
UNSPSC 11 | 39121432 |
UNSPSC 12.01 | 39121409 |
UNSPSC 13.2 | 39121409 |
UNSPSC 18.0 | 39121409 |
UNSPSC 19.0 | 39121409 |
UNSPSC 20.0 | 39121409 |
UNSPSC 21.0 | 39121409 |
Title: | Size: | Type: |
---|---|---|
PDF CATALOG PHOENIX PCB CONNECTORS EN.pdf | 15 Mbytes |
