> OMRON>Vision Systems>Special >VPB85027 AA053577E OMRON Bandpass filter 850 nm, M27x0.5
ANUNCIAR
Previous Product Next Product
VPB85027 AA053577E OMRON Bandpass filter 850 nm, M27x0.5 View larger
Images are for illustrative purposes only. Please refer to data sheet for details.

VPB85027 AA053577E OMRON Bandpass filter 850 nm, M27x0.5

VPB85027

AA053577E

OMRON

Bandpass filter 850 nm, M27x0.5

More details


Sensors > Accessories/spare parts for sensor technology

Vision Systems > Special Vision

Brand new product in its original packaging covered by the warranties and certifications provided by OMRON

Total: $365.66
Unit price: $365.66
This price is per unit and is the net value (not including taxes if applicable).

If our price is not the best, please ask us for a quote. Ask for a quotation

Best sellers

▲

More info

▲


Features

Compact 3-phase input power supply

The 3 phase S8VK-T series adds to the compact Power Supply range (from 120W up to 960W), giving you the best footprint size. Just like the single phase type S8VK-G. It has the wide acceptable input range including 3-Phase input (3 x 340 to 576 VAC) 2-Phase input (2 X 340 to 576 VAC) and DC input excluding 960W (450 to 810 VDC)

  • Wide operating temperature range (-40 to +70ºC) to guarantee operation stability
  • Double set of DC output terminals (three for the negative) to provide easy wiring
  • High efficiency (90%) to reduce energy consumption
  • Power Boost functionality (120%)
  • High vibration resistance with Metal DIN-rail mounting clip.

Ordering information

Type

Power ratings

Input voltage

Output voltage

Output current

Size (W × H × D) [mm]

Order code

Standard models

Coated models

Power supply three-phase

120 W

3 × 380 to 480 VAC,
2 × 380 to 480 VAC
450 to 600 VDC (Excluding 960 W)

Allowable range:
3 × 320 to 576 VAC,
2 × 340 to 576 VAC,
450 to 810 VDC (Excluding 960 W)

24 V

5 A

40×125×113

S8VK-T12024

S8VK-T12024-400

240 W

10 A

60×125×140

S8VK-T24024

S8VK-T24024-400

480 W

20 A

95×125×140

S8VK-T48024

S8VK-T48024-400

960 W

40 A

135×125×170

S8VK-T96024

S8VK-T96024-400

Specifications

Item

120 W

240 W

480 W

960 W

Efficiency (Typ. at 400 VAC)

89%

89%

91%

92%

Input

Rated Input Voltage

3 × 380 to 480 VAC, 2 × 380 to 480 VAC, 450 to 600 VDC

3 × 380 to 480 VAC,
2 × 380 to 480 VAC

Allowable range

3 × 320 to 576 VAC, 2 × 340 to 576 VAC, 450 to 810 VDC

3 × 320 to 576 VAC,
2 × 340 to 576 VAC

Output

Voltage adjustment range (with V.ADJ)

22.5 to 29.5 V

Input variation influence

0.5% max. (at 3 × 320 to 576 VAC input, 100% load)

Load variation Influence

1.5% max. at 0 to 100% load

Temperature variation influence

0.05%/°C max.

Overload protection

Yes, 125% of rated current typ.

Power Boost

120% of rated current

Overvoltage protection

Yes

Operating ambient temperature

−40 to 70°C (−40 to 158°F)

Series Operation

Yes, Up to 2 units

Parallel Operation

Yes, Up to 2 units

EMI

Conforms to EN 61204-3, EN 55011 Class B

EMS

Conforms to EN 61204-3 high severity levels

Harmonic current emissions

Conforms to EN 61000-3-2

Approved Standards

UL: UL 508 (Listing),

ANSI/ISA 12.12.01

EN/VDE: EN 50178,

Lloyd’s Register

UL: UL 508 (Listing), ANSI/ISA 12.12.01, UL 60950-1, CSA: C22.2 No.60950-1,

EN/VDE: EN 50178, EN 60950-1,

Lloyd’s Register

Fulfilled Standards

SELV (EN 50178), PELV (EN 60204-1, EN 50178),
Safety of Power Transformers (EN 61558-2-16), EN 50274 for Terminal parts

SELV (EN 60950-1/EN 50178/UL 60950-1), PELV (EN 60204-1, EN 50178),

Safety of Power Transformers (EN 61558-2-16), EN 50274 for Terminal parts

Degree of protection

IP20 by EN / IEC 60529

Datasheet - PDF

▲
Title: Size: Type:
PDF CATALOG OMRON 2024 EN.pdf 25 Mbytes
VPB85027 VPB85027 AA053577E t061_s8vk_t_switch_mode_power_supply_datasheet_en.pdf 2 Mbytes VPB85027 VPB85027 AA053577E t061_s8vk_t_switch_mode_power_supply_datasheet_en.pdf
