S8VS-09024BP S8VS0131D S8VS09024BP,1 OMRON 90W / 24V / 3,75 DIN Displ. Time func. Alarm PNP
S8VS-09024BP
S8VS0131D
S8VS09024BP.1
OMRON
90W / 24V / 3,75 DIN Displ. Time func. Alarm PNP
90W / 24V / 3.75A DIN Displ. Time func. PNP Alarm
Power supply, 90W, 100-240 VAC input, 24 VDC 3.75A output, DIN rail mounting, digital display with running voltage and current, peak current, and tota
Low-voltage industrial components > DC-power supply
Power supplies > S8VS
Brand new product in its original packaging covered by the warranties and certifications provided by OMRON
Best sellers
▲More info
▲Power Supply with a display
The S8VS-A/B series are AC to DC Power supplies with a display of output voltage, output current, and peak hold current. The A type S8VS has a function to show the maintenance forecast time in operational years. This will contribute to the equipment maintence and allow for replacement before the end of product life. The B type has a function of total run time monitor to allow the user to properly schedule equipment maintenance.
- Operating temperature range (-10 to +60ºC)
- The 3 digit, 7 segment display
- The alarm output(Transistor:PNP, NPN)
- The screwless terminal type is available
- cULus, EN, RoHS compliant
- UL Class 2 output( 60W and 90W)
| Feature Name | Feature Value |
|---|---|
| Degree of protection (IP) (EF005474) | Other |
| Type of electric connection (EF003961) | Screw connection |
| Voltage type (supply voltage) (EF002991) | AC |
| Wall mounting possible (EF003973) | Yes |
| Suitable for rail mounting (EF003972) | Yes |
| Max. output current 1 (EF008284) | 3.75 A |
| Built-in height (EF000332) | 121.3 mm |
| Built-in width (EF000846) | 50.000 mm |
| Width in number of modular spacings (EF002950) | 1 |
| Width (EF000008) | 50 mm |
| Height (EF000040) | 115 mm |
| Power output (EF003034) | 90 W |
| Depth (EF000049) | 121.3 mm |
| Rated supply voltage AC 50 Hz (EF007076) | 100 V |
| Rated supply voltage AC 60 Hz (EF007077) | 100 V |
| 1st secondary output voltage (EF006792) | 21.6 V |
Datasheet - PDF
▲| Title: | Size: | Type: |
|---|---|---|
| PDF CATALOGO OMRON AUTOMATION EN.pdf | 19 Mbytes |
|
| PDF CATALOG OMRON 2024 EN.pdf | 25 Mbytes |
|
| S8VS-09024BP S8VS09024BP.1 S8VS0131D t026_s8vs_switch_mode_power_supply_datasheet_en.pdf | 5 Mbytes |
|
