D40ML-M2-U-M12 AA044827R 669719 OMRON Magnetic Lock Switch PLe RFID Single Metal Fund. 900N M12
D40ML-M2-U-M12
AA044827R
D40MLM2UM12
OMRON
Switch Magnetic Lock PLe RFID Single Metal Fund. 900N M12
Magnetic Lock Switch PLe RFID Single Metal Fund. 900N M12
RFID Magnetic Locking Safety Switch, Die-cast Metal, 900N, Unique Actuator Code, Pigtail w/M12 Connector
Safety > Contactless Switches TGR
* Brand new product in its original packaging covered by the warranties and certifications provided by OMRON
More info
▲Specifications
| Door switch type | RFID magnetic |
| Guard-lock | |
| Coding | Unique |
| Material housing | Diecast metal |
| Ambient temperature (operating) | -25-40 °C |
| Holding force | 900 N |
| Door contacts NC | 2 |
| Door contacts NO | 0 |
| Lock monitor contacts NC | 0 |
| Lock monitor contacts NO | 1 |
| Lock/Release key type | N/A |
| Solenoid voltage | 24 V |
| With LED indicator | |
| Connection method | M12 pigtail connector |
| Cable length | 0.25 m |
| Degree of protection (IP) | IP67 |
| Overall length | 96 mm |
| Height of sensor | 37 mm |
| Width sensor | 64 mm |
| Switch without actuator | |
| Lock/Release logic | Power to lock (Solenoid lock) |
Datasheet - PDF
▲| Title: | Size: | Type: |
|---|---|---|
| D40ML-M2-U-M12 669719 AA044827R EN_D40ML-SS2-B-10M.pdf | 434 Kbytes |
 |
| D40ML-M2-U-M12 669719 AA044827R f22e_d40ml_rfid_magnetic_locking_safety_switches_datasheet_en.pdf | 397 Kbytes |
|
