BT-WIN 3P W 6108952 OBO BETTERMANN 3-pole connector, WINSTA 76x35x15 white Polyamide, PA
BT-WIN 3P W
6108952
OBO BETTERMANN
3-pole connector, WINSTA 76x35x15 white Polyamide, PA
Socket section 3-pin, white. Socket section 3-pin, type WINSTA® MIDI with clamp connection.Single and multi-wire cables connectable without end sleeve. Not mounted with strain relief and terminable in situ. 250 V, 25 A.Nominal cross-section: 2.5 mm²Stripping length: 55 mmInsulation removal length: 9 mm
EGS device systems - OBO BETTERMANN
Brand new product in its original packaging covered by the warranties and certifications provided by OBO BETTERMANN
Related products
▲Best sellers
▲More info
▲| Built-in variants | Installation part/plug connection |
|---|---|
| CO2 Footprint (GWP) Cradle-to-Gate | 0,1074 kg CO2e / 1 Piece |
| Colour | White |
| Contact material | CuSn |
| Dimension | 76x35x15 |
| Direction of insertion | Straight |
| Halogen-free | yes |
| Height | 15 mm |
| Length | 76 mm |
| Material | Polyamide |
| Mechanical encoding | yes |
| Nominal current | 25 A |
|---|---|
| Nominal voltage | 250 V |
| Pin labelling | L, N, PE |
| Plug-in system | WINSTA® MIDI |
| Pole number | 3 |
| Protection rating | IP20 |
| Surface treatment of the contacts | Miscellaneous |
| Type of locking | Integrated in plug connector |
| Version of the device connection | socket |
| Width | 35 mm |
Datasheet - PDF
▲| Title: | Size: | Type: |
|---|---|---|
| PDF CATALOGUE INSTALLATION SYSTEMS OBO EN.pdf | 23 Mbytes |
|
