2CKA006220A0723 DA-M-0.4.127.2 NIESSEN Actuator DIN 4-channel 127V
2CKA006220A0723
DA-M-0.4.127.2
NIESSEN
Actuator DIN 4-channel 127V
Dimactuator 4-g, MDRC, 127
Installation bus systems > Dimming actuator for bus system
Home > NIESSEN
Brand new product in its original packaging covered by the warranties and certifications provided by NIESSEN
Best sellers
▲More info
▲| Installation | |
|---|---|
| Mounting Type | DIN-Rail |
| Environmental | |
| Ambient Air Temperature | Operation -5...45 °C |
| Degree of Protection | IP20 |
| Technical | |
| Compatible Bus Systems | free@home (TP) |
| Product Range | free@home |
| Electrical | |
| Rated Voltage (Ur) | 230 V |
| Rated Frequency (f) | 50...60 Hz |
| Dimensions | |
| Width in Number of Modular Spacings | 8.0 |
| Product Net Width | 96 mm |
| Product Net Height | 85 mm |
| Product Net Depth / Length | 175 mm |
| Product Net Weight | 480 g |
| Material Compliance | |
| RoHS Declaration | 2CKA200000E5334 |
| RoHS Information | Following EU Directive 2011/65/EU and Amendment 2015/863 July 22, 2019 |
| Conflict Minerals Reporting Template (CMRT) | 9AKK108468A3363 |
Datasheet - PDF
▲| Title: | Size: | Type: |
|---|---|---|
| PDF CATALOGUE KNX & SOLUTION FOR BUILDINGS EN.pdf | 88 Mbytes |
|
| PDF CATALOGUE NIESSEN EN .pdf | 36 Mbytes |
|
| 2CKA006220A0723 DA-M-0.4.127.2 EN_2CKA006220A0723.pdf | 154 Kbytes |
|
