857725 MURRELEKTRONIK MCS power supply 2-phase IN: 340-460VAC OUT: 24-28V/5ADC
857725
MURRELEKTRONIK
MCS power supply 2-phase IN: 340-460VAC OUT: 24-28V/5ADC
MCS POWER SUPPLY 2-PHASE,IN: 340-460VAC OUT: 24-28V/5ADC
Power supplies
Brand new product in its original packaging covered by the warranties and certifications provided by MURRELEKTRONIK
Best sellers
▲More info
▲| Art.No.: | 857725 |
| Weight: | 0.8 kg |
OUTPUT: 24...28 V DC
Current: 5 A
| Input voltage | 340...470 V AC |
|---|---|
| Input current | 0.85 A (400 V AC) |
| Inrush current after 1 ms | max. 22 A |
| Primary fusing external | max. 10 A |
| Frequency | 50...60 Hz |
| Standards | EN 60950-1, EN 61204-3, EN 55022 B |
|---|---|
| Mounting method | DIN-rail mountable TH35 (EN 60715) |
| Efficiency | 88% (400 V AC) |
| Relative humidity | 5...95%, no condensation |
| Dimensions H × W × D | 127×68×140 mm |
| Temperature range | 0...+60 °C (storage temperature -25...+85 °C) |
| Output voltage | 24 V DC (SELV), ±1%; 24...28 V adjustable |
|---|---|
| Output current | 5 A (+60 °C); 6 A (+40 °C) |
| Mains failure bridging time | min. 10 ms (400 V AC) |
| Ripple | max. 20 mV eff/rms |
| Spikes | max. 100 mV ss/pp |
| Unit protection | Short-circuit and overload protected |
| LED display | LED (green) for output voltage |
| Selectable switch-off mode | front sided plug link (automatic re-start or definite shut-off) |
| Parallel usage/serial usage | max. 5 units/max. 2 units |
| country of origin | CZ |
|---|---|
| customs tariff number | 85044090 |
| EAN | 4048879076401 |
| eClass | 27049002 |
| Packaging unit | 1 |
Datasheet - PDF
▲| Title: | Size: | Type: |
|---|---|---|
| PDF CATALOG MURRELEKTRONIK EN.pdf | 36 Mbytes |
|
| 857725 857725 857725_Data_Sheet_1.pdf | 122 Kbytes |
|
