85041 MURRELEKTRONIK MCS power supply 1-phase IN: 90-265VAC OUT: 4-6V/6ADC
85041
MURRELEKTRONIK
MCS power supply 1-phase IN: 90-265VAC OUT: 4-6V/6ADC
Power supplies
Brand new product in its original packaging covered by the warranties and certifications provided by MURRELEKTRONIK
Best sellers
▲More info
▲| Art.No.: | 85041 |
| Weight: | 0.45 kg |
OUTPUT: 5 V DC ±1%
Current: 6 A
| Input voltage | 100...240 V AC |
|---|---|
| Input current | 0.5 A (115 V AC); 0.3 A (230 V AC) |
| Inrush current after 1 ms | max. 22 A |
| Primary fusing external | max. 10 A |
| Frequency | 50...60 Hz |
| Standards | EN 60950-1, EN 61204-3, EN 55022 B, EN 61000-3-2 |
|---|---|
| Relative humidity | 5...95%, no condensation |
| Efficiency | 80% |
| Mounting method | DIN-rail mountable TH35 (EN 60715) |
| Dimensions H × W × D | 107.5×42×97.5 mm |
| Temperature range | 0...+60 °C (storage temperature -25...+85 °C) |
| Output voltage | 5 V DC (SELV), ±1%, 4...6 V adjustable |
|---|---|
| Output current | 6 A (+60 °C); 7.5 A (+50 °C) |
| Mains failure bridging time | min. 12 ms (115 V AC); min. 90 ms (230 V AC) |
| Ripple | max. 10 mV eff/rms |
| Spikes | max. 50 mV ss/pp |
| Unit protection | Short-circuit and overload protected |
| LED display | LED (green) for output voltage |
| Parallel usage/serial usage | no/yes (max. 2 units) |
| country of origin | CZ |
|---|---|
| customs tariff number | 85044090 |
| EAN | 4048879080743 |
| eClass | 27049002 |
| Packaging unit | 1 |
Datasheet - PDF
▲| Title: | Size: | Type: |
|---|---|---|
| PDF CATALOG MURRELEKTRONIK EN.pdf | 36 Mbytes |
|
| 85041 85041 85041_Data_Sheet_1.pdf | 103 Kbytes |
|
