7000-SS021-8841400 MURRELEKTRONIK M23 Servo Cable Specification: 6FX7002-5EA05-1BA0
7000-SS021-8841400
MURRELEKTRONIK
M23 Servo Cable Specification: 6FX7002-5EA05-1BA0
DRIVE CLIQ CABLESpecification: 6FX2002-1DC00-1BE0
DRIVE CLIQ CABLE
Connectors with cable
Brand new product in its original packaging covered by the warranties and certifications provided by MURRELEKTRONIK
Best sellers
▲More info
▲Male straight – male straight
DRIVE-CLIQ IP20 – DRIVE-CLIQ IP20, 10-pole
Further cable lengths on request. The resistance to aggressive media should be individually tested for your application. Further details on request.
| Form | SS021 |
|---|
| Cable number | 884 |
|---|---|
| No./diameter of wires | 2× 2× 0.22 mm² |
| Wire isolation | PE (gn, ye, pk, bl) |
| Jacket Color | gray |
| Material (jacket) | PVC (UL/CSA) |
| Specification | 6FX2008-1DC00 |
| Outer Ø | 6.9 mm ±5% |
| Bend radius (fixed) | 7.5× outer Ø |
| Bend radius (moving) | 15× outer Ø |
| Temperature range (fixed) | -20...+80 °C |
| Temperature range (mobile) | 0...+60 °C |
| Shield | yes |
| Operating voltage | max. 30 V AC/DC |
|---|---|
| Rated surge voltage | 0.5 kV |
| Operating current | max. 1.76 A |
| Material group | IEC 60664-1, category II |
| Locking of ports | DRIVE-CLiQ-System |
| Protection | IP20 |
| Pollution Degree | 3 |
|---|---|
| Temperature range | -20...+80 °C, depending on cable quality |
| country of origin | DE |
|---|---|
| customs tariff number | 85444210 |
| EAN | 4048879813112 |
| eClass | 27061801 |
| Packaging unit | 1 |
Datasheet - PDF
▲| Title: | Size: | Type: |
|---|---|---|
| PDF CATALOG MURRELEKTRONIK EN.pdf | 36 Mbytes |
|
| 7000-SS021-8841400 7000-SS021-8841400 EN_7000-SS021-8841400.pdf | 98 Kbytes |
|
