UT5L/G4-1ESY MICRO DETECTORS Ultrasonic sensor M30 housing with large shape transducer ø 61mm, analogic 4-20..
UT5L/G4-1ESY
MICRO DETECTORS
Ultrasonic sensor M30 housing with large shape transducer ø 61mm, analogic 4-20 mA+ NPN NO/NC 600-8000 mm, conn. M12 with teach-in button,AISI316L stainless steel housing, cULus
Encoders
Brand new product in its original packaging covered by the warranties and certifications provided by MICRO DETECTORS
Best sellers
▲More info
▲Technical features
Detection properties
| Nominal sensing distance | 8000mm | |
| Thermal drift of Sr | ±5% | |
| Repeat Accuracy | 1% valore fondoscala | |
| Beam angle | 10° ± 2° | |
| Resolution | 1% valore fondoscala | |
| Sensitivity adjustment | bottone teach-in | |
| Hysteresis | 1% valore fondoscala | |
| thermal compensation | Sì | |
| Minimum sensing distance (blind zone) | 600mm | |
| Linearity error | 1% valore fondoscala | |
Outputs
| Output type | analog+digitale | |
| Output Function | rampa positiva | |
| Switching frequency | 1Hz | |
| Response time | 1s | |
Electrical data
| Operating Voltage | 10 - 30Vdc | |
| No-Load supply current | 25mA | |
| Load current | 100mA | |
| Leakage current | ≤ 10µA @ 30Vdc | |
| Output voltage drop | 2,2V max @ IL=100mA | |
| Max ripple content | 5% | |
| LED indicators | Verde: Eco - Giallo: Uscita | |
| Time delay before availability | ≤400ms | |
| Short-circuit protection | Sì | |
| Reverse Polarity Protection | Sì | |
| Impulsive Overvoltage Protection | Sì | |
Mechanical data
| Dimensions | ø 61mm / L = 115mm | |
| Weight | 400g | |
| Housing Material | AISI316L | |
| Connections | M12 Plug | |
| Tightening torque | 100Nm | |
| Operating temperature | -20°C…+70°C | |
| Storage temperature | -30°C…+80°C | |
| Transducer Frequency | 40KHz | |
Test/Approvals
| Approvals | CE cULus | |
| EMC compatibility | IEC 60947-5-2 | |
| Shocks and vibrations | IEC EN 60947-5-2 / 7.4 | |
| Degree of protection | IP67 | |
Accessories
| Supplied Accessories | 2 x M30x1,5 dadi | |
Dimension (mm)
Datasheet - PDF
